Sonation Lab Solutions SSH22-41U Noise Reduction Box

Product Information

The Sonation Lab Solutions SSH22-41U Noise Reduction Box is a class 3 service used pump accessory that provides accommodation and sound insulation for two pumps in the same box. It features temperature monitoring with an alarm, four temperature-controlled fans with speed monitoring, IEC 10A power outlets, and wide-range input of 100-250V AC. The robust, powder-coated construction ensures a tough, washable, and hygienic surface. The ingenious air piping system maximizes heat elimination and acoustic insulation, achieving noise reduction of up to 16 dB. The unit is equipped with advanced technology to ensure optimal performance and safety, making it an ideal choice for laboratories and research facilities. Whether used for vacuum pumps, MS, or wall outlet connections, the SSH22-41U delivers reliable, secure, and efficient operation.

• Accommodation and sound insulation for two pumps in one box
• Temperature monitoring with alarm and four controlled fans
• IEC 10A power outlets and wide-range input of 100-250V AC
• Robust, all-metal construction with powder-coated, washable, hygienic surface
• Ingenious air piping system for maximum heat elimination and acoustic insulation
• Achieves noise reduction of up to 16 dB

• Temperature monitoring with alarm and four temperature-controlled fans
• IEC 10A (C13/C14) power outlets with current monitoring and emergency shutdown
• Exterior dimensions: 550 x 300 x 750 mm (WxHxD)
• Interior dimensions: 500 x 275 x 650 mm (WxHxD)
• Robust all-metal construction, powder coated in RAL 5012 light blue
• High-grade insulant made of recycled material, oil and water repellent
• Ingenious air piping system for maximum heat elimination and acoustic insulation
• Achieves noise reduction of up to 16 dB
• Wide input range: 100-250V AC (50/60 Hz)
• Two-part cover sheet that is adaptable for many different pumps
• Easy installation and access for servicing purposes
• Equipped with four temperature-controlled and function-monitored fans for ventilation
• Airflow up to 640m/h (380cfm), temperature controlled
• Loads of up to 2x10A can be connected to the inner power outlets

Metric: 90.7 kg
Imperial: 200 lbs

Metric: 55 cm x 30 cm x 75 cm
Imperial: 21.65 in x 11.81 in x 29.53 in

841490

Air conditioning machines, comprising a motor-driven fan and elements for changing the temperature and humidity, including those machines in which the humidity cannot be separately regulated.
