Applied Biosystems 4376592R Real Time PCR System

Product Information

Introducing the Applied Biosystems 4376592R Real Time PCR System, a 96-well Real-Time PCR instrument that caters to both first-time and seasoned users, guaranteed to lay the foundation for precise, quantitative Real-Time PCR results across a diverse range of genomic research applications. **Unit powers on but heating block does not heat up. NEEDS repair. The StepOnePlus Real-Time PCR System features robust LED based 4-color optical recording, ensuring accurate calibration with a dynamic range of greater than 9 log units and a detection range for in-depth genomic exploration. It combines sustainable packaging with high throughput compatibility, leveraging multiplexing optics with sensitivities as low as 1 copy. With reaction volume ranges of 10-30 l and a temperature range of 4-100C, the StepOnePlus promotes flexibility, catering to the variable needs of your genetic research applications. The Thermal Cycling System is Peltier-Based, ensuring efficient and accurate application of temperatures, further reinforced by its superior temperature uniformity and accuracy to chromatograph your genetic material effectively. Sensible researchers aren't just stockpiling data, they're using the right tools for the right job.

• LED based 4-color optical recording
• Dynamic range greater than 9 log units
• Linear detection method for precise genomic research
• High throughput compatibility with multiplexing capabilities
• Temperature uniformity of 0.25C from 35 to 95C

• Calibrated Dye: FAM, JOE, NED, ROX, SYBR Green I, TAMRA, VIC
• Capacity: 1 x 96-well plate, 12 x 8-tube strips, 96 x 0.1 ml tubes
• Detection Method: Primer-Probe Detection, SYBR
• Dimensions: 24.6 cm/9.7 in.(W) x 42.7 cm/16.8 in.(D) x 51.2 cm/20.2 in.(H)
• Dynamic Range: Linear Dynamic Range greater than 9 log units (detection)
• For Use With (Equipment): StepOnePlus
• Format: 0.1 ml tubes, 8-tube strips, 96-well plate
• Green Features: Sustainable packaging
• High Throughput Compatibility: Multiplexing
• Optics: 4 emission filters, Blue LED excitation source, photodiode
• Passive Reference Dye: No ROX, ROX (Pre-mixed), ROX (Separate Tube)
• Peak Block Ramp Rate: 4.6Csec
• Product Line: StepOnePlus
• Product Size: 1 instrument
• Reaction Speed: Fast, Standard
• Reaction Volume Range: 10-30 l (Standard curve experiments: 40 l in standard mode is validated)
• Run Time: <2 hrsrun (Standard Mode), <40 minrun (Fast Mode)
• Sample Ramp Rate: Fast mode: 2.2Csec, Standard mode: 1.6Csec
• Sensitivity: 1 copy
• Temperature Accuracy: 0.25C (35 to 95C) of display temperature
• Temperature Range (Metric): 4-100C
• Temperature Uniformity: 0.25C (35 to 95C) of setpoint/display temperature
• Thermal Cycling System: Peltier-Based System

Metric: 20 kg
Imperial: 45 lbs

Metric: 24 cm x 24 cm x 51.2 cm
Imperial: 9.45 in x 9.45 in x 20.16 in

9027.10.20

9027 Instruments and apparatus for physical or chemical analysis- chromatographs and electrophoresis instruments
