Matrix Well Mate 8-Channel Fluid Dispenser for 96- and 384-Well Microplates

Product Information

The Matrix Well Mate 8-Channel Fluid Dispenser is a high-speed, compact instrument designed for repetitive and precise dispensing of samples and reagents into 96- and 384-well microplates. The intuitive programming capabilities allow setting dispense volumes and plate types. The instrument offers a dynamic dispense volume range from 2.0 µL to 2000 µL, along with a stepper-motor technology for fast and accurate dispensing. The unique feature of the Well Mate, making it highly cost-effective, is the low-cost, replaceable tubing cartridges. Despite being sold 'as-is', this used instrument carries huge potential for efficient and accurate liquid handling tasks in laboratories.

• Preset capabilities for dispensing protocols
• Customizable dispense volumes and plate types
• Low-cost, replaceable tubing cartridges
• Memory-storage capacity for 18 files
• Full RS-232 programming for ease of integration

• Dynamic dispense volume range: 2.0 µL to 2000 µL
• 8-channel, standard-bore disposable tubing cartridge inner diameter nozzle orifice: 0.023in (0.58mm)
• Recommended dispense volumes: 20 µL to 2000 µL, 2 µL to 200 µL
• Dispense accuracy/precision: +/-2.0% or 1.0 µL, +/- 4.0% or 0.4 µL: < 20 µL; +/- 2.0%: > 20 µL
• Power Supply: AC 100-240V, 50/60Hz 40VA

Metric: 14.968 kg
Imperial: 33 lbs

Metric: 20.32 cm x 20.32 cm x 20.32 cm
Imperial: 8 in x 8 in x 8 in
