Applied Biosystems 7300 Real Time PCR

Product Information

Welcome fellow scientists! Today, we delve into the realms of genetic exploration with the Applied Biosystems 7300 Real Time PCR. This robust yet compact PCR tool is a gem in quantifying nucleic acid sequences without compromising data integrity. With the ability to run PCR without the need for purification, gel runs, or post PCR alterations, the ABI 7300 performs real-time PCR swiftly, providing quick and reliable results even in a tight lab space. Manufactured specifications reveal a Peltier-based thermal cycling system housed in a 96-well block with a sample ramp rate of 1.1C/sec and the ability to detect four colors. This versatile equipment has multiple applications such as SNP genotyping, pathogen quantification, gene expression analysis and plus/minus assays using internal positive controls.

• Thermal cycling system based on Peltier technology
• Multiple application capabilities including SNP genotyping and gene expression analysis
• Ability to detect four colors
• Real-time PCR runs in less than two hours using tubes, 96 well plates and 8-strip tubes
• Volume range from 20-100L

• Thermal cycling system: Peltier-based, 96-well block
• Sample Ramp Rate: 1.1C/sec
• Peak Block Ramp Rate: 1.6C/sec
• Temperature Range: 4C - 100C
• Temperature Accuracy: 0.25C of setpoint
• Temperature Uniformity: 0.50C
• Optical system: Single excitation, four emission filters, and CCD camera
• Calibrated Dyes at Installation: SYBR Green, FAM, JOE, NED, TAMRA, ROX
• Quantitative PCR run time: < 1 hour 50 minutes
• Supported Volumes: 20 - 100 L
• Supported Consumables: Standard optical 96 well plates, 0.2ml tubes, Optical adhesive covers, Optical flat caps, 8-strip 0.2ml tubes

Metric: 29.48 kg
Imperial: 65 lbs

Metric: 17.0 cm x 14.0 cm x 21.0 cm
Imperial: 6.69 in x 5.51 in x 8.27 in
