Systec Stand Alone MINI Vacuum Degassing System for HPLC 0001-6410 Used 30-Day Warranty

Product Information

Greetings, fellow scientists! Let's delve into the Systec Stand Alone MINI vacuum degassing system for HPLC. This high-efficiency inline module is a marvel of technology, removing dissolved gases from HPLC mobile phases with unparalleled precision. The flow-through vacuum degassing chamber boasts a single, inert, amorphous perfluorinated copolymer (Systec AF) degassing membrane, delivering a degassing efficiency 50 times that of PTFE. It's like a deep breath of fresh laboratory air, ensuring that your analysis is free from pesky gas interference. The Systec Stand Alone MINI vacuum degassing system for HPLC will optimize your degassing process, offering not just efficiency but uncompromising precision. The setup ensures O2 removal at 1mL/min MeOH at a staggering efficiency of over 70%. It's the unsung hero of your HPLC experiments, silently working to enhance the purity and reliability of your results. It's not compatible with fluorinated solvents, standing as a testament to its specialized utility. Its pressure drop estimation of 0.18 kPa/mL/min caters to laminar flow scenarios, offering a seamless workflow. With a maximum pressure of 0.5 MPa (70 psi) at 25°C, the vacuum degassing system proves its robust nature. The validation output signals at 5mV DC and ensures an accuracy of 1.0% of reading. This powerful system is a game-changer, offering a host of unique features and unparalleled precision. It's the silent champion in your laboratory, ready to elevate your HPLC experiments to new heights.

• High-efficiency inline module for removing dissolved gases from HPLC mobile phases
• Features a single, inert, amorphous perfluorinated copolymer (Systec AF) degassing membrane
• Degassing efficiency >70% O2 removal at 1mL/min MeOH
• Not compatible with fluorinated solvents
• Maximum pressure of 0.5 MPa (70 psi) at 25°C
• Validation output signals at 5mV DC with accuracy of 1.0% of reading

• Degassing Efficiency: >70% O2 removal at 1mL/min MeOH. Can be optimized based on flow rate, fluid, and gas
• Solvent Compatibility: Not compatible with fluorinated solvents
• Degassing Line Path Int.: 1.14 mm (0.045")
• Pressure Drop: 0.18 kPa/mL/min (estimated tubing pressure per unit change in flow)
• Max. Pressure: 0.5 MPa (70 psi) at 25°C
• Validation Output: Signal - 5mV DC; Accuracy - 1.0% of reading, 0.010V DC from 2.7 to 106.7 kPa

Metric: 5.44311 kg
Imperial: 11.999404 lbs

Metric: 30.48 cm x 20.32 cm x 22.86 cm
Imperial: 12.0 in x 8.0 in x 9.0 in

9027200000

The chosen harmonized code is 9027200000, which pertains to gas or smoke analysis apparatus. This code accurately represents the nature of the Systec Stand Alone MINI vacuum degassing system for HPLC, which functions to remove dissolved gases from HPLC mobile phases with exceptional precision and efficiency.
