Keyence SJ-F2000 Ionizing Equipment for Laboratory Use

Product Information

Introducing the Keyence SJ-F2000 single Static Eliminators/Ionizer. This equipment is in good used condition and is the perfect addition to any lab setting. The SJ-F2000 serves as a powerful Pulse AC Ionizer with an applied voltage of 7000V and an ion balance of 5V. It is capable of eliminating static in approximately 1 second, making it ideal for maintaining a controlled laboratory environment. The maximum operating distance of 50mm ensures efficient static elimination, and the equipment boasts a maximum air volume of 2.5m3/min (88.29 CFM) for thorough coverage. With a power voltage of 24VDC and consumption of 0.9A, the SJ-F2000 is an essential tool for any lab working with sensitive electronic components or materials.

• Pulse AC method for voltage application
• 7000V applied voltage for effective ionization
• Ion balance control method with 5V balance
• Approximately 1-second static elimination time
• Maximum operating distance of 50mm
• High maximum air volume of 2.5m3/min (88.29 CFM)
• Power voltage of 24VDC and low consumption of 0.9A

• Voltage Application Method: Pulse AC method
• Applied Voltage: 7000V
• Ion Balance Control Method: I.C.C.
• Ion Balance: 5 V*1
• Static Elimination Time: Approx. 1 sec*2
• Operating Distance: 50 mm (1.97 in) min.
• Maximum Air Volume: 2.5 m3/min (88.29 CFM)
• Power Voltage: 24 VDC 10%
• Current Consumption: 0.9 A
• Pollution Degree: 2
• Ambient Temperature: 0 to +50°C (32 to 122°F)
• Relative Humidity: 35 to 65% RH

Metric: 4.08 kg
Imperial: 9 lbs

Metric: 33.02 cm x 12.7 cm x 22.86 cm
Imperial: 13 in x 5 in x 9 in

902790

902790 - Other instruments and apparatus for physical or chemical analysis
