Edwards E2M28 Rotary Vane Vacuum Pump - Lab Equipment, Needs Repairs

Product Information

The Edwards E2M28 Rotary Vane Vacuum Pump offers excellent ultimate pumping speed while providing quiet operation. With outstanding vapor handling capabilities, the E2M28 is a reliable and versatile 208V vacuum pump. The unit is easy to use and service, featuring a fast-acting inlet valve to prevent oil and gas suck-back. It is suitable for various applications such as sterilization, mass spectrometry, lasers, vacuum distillation, epoxy degassing, brake line evacuation, freeze drying, space research, refrigeration dehydration, vacuum ovens, backing combinations, thin film coating, and other vacuum processes. Despite needing a rebuild and being sold as-is, this pump presents high vacuum or high throughput, selectable modes, adjustable gas ballast control, and three user-selectable gas ballast positions. With a pressure gauge measuring 97 microns, a maximum pressure of 1.5 x 10-3mbar, 0.5 hp horsepower, 48 dB noise level, and a flow rate of 76 L/min, this pump comes with various accessories including a 2m electrical supply cable, inlet screen, Ultra grade 19 Oil, and a lifting bracket.

• Outstanding vapor handling capabilities
• Fast-acting inlet valve to prevent oil and gas suck-back
• Pressure gauge measures 97 microns
• Selectable modes for high vacuum and high throughput
• Adjustable gas ballast control
• Comes with various accessories

• Maximum Pressure: 1.5 x 10-3mbar
• Horsepower: 0.5 hp
• Noise Level: 48 dB (A)
• Flow Rate: 76 L/min
• Includes: Pump, 2m electrical supply cable, inlet screen, Ultra grade 19 Oil, lifting bracket

Metric: 47.174 kg
Imperial: 104.0 lbs

Metric: 18 cm x 7 cm x 16 cm
Imperial: 7.0866 in x 2.7559 in x 6.2992 in

8414909000

Vacuum pumps of a kind used in laboratories
