GE AKTApilot Liquid Chromatography System (LC) 56317181

Product Information

The GE AKTApilot Liquid Chromatography System (LC) 56317181 is a high-performance, automated liquid chromatography system designed for process development, process scale-up and scaledown, and small-scale production. It is biocompatible, hygienic, and subitizable, meeting all GLP and cGMP demands for Phase IIII in drug development and small-scale production. The system consists of the KTApilot separation unit, the connected computer including a flat-screen monitor, and the UNICORN control system. It provides liquid flow rates from 4 to 800 ml/min, operating pressure up to 20 bar, and contains all the fluid handling components required to perform buffer delivery and mixing, sample application, and in-line monitoring. It is equipped with detectors for continuous in-line measurement of pH, conductivity, and UV absorbance. The KTApilot minimizes preparation time by allowing rapid media screening, method scouting and optimization, as well as scale-up experiments. Convenient sample application, column packing, and pressure monitoring are also possible.

• Automated liquid chromatography system
• KTApilot separation unit
• UNICORN control system
• Liquid flow rates from 4 to 800 ml/min
• Continuous in-line measurement detectors

• Liquid flow rates: 4 to 800 ml/min
• Operating pressure: up to 20 bar
• Detector measurements: pH, conductivity, UV absorbance
• Method templates for rapid media screening and optimization
• Subitizable system, meeting GLP and cGMP demands

Metric: 132.44 kg
Imperial: 292 lb

Metric: 30 cm x 38 cm x 48 cm
Imperial: 11.81 in x 14.96 in x 18.9 in

9027200000

The harmonized code 9027200000 for liquid chromatography instruments is used for liquid chromatography and chromatographs. This code applies to instruments for analyzing or measuring the concentration of constituents in a liquid.
