Kinematic Automation Matrix 2501 Rotary Slitting Module CE M2501 Drive Module w/Std Infeed
- Make Kinematic Automation
- Hertz 50Hz/60Hz
- Model CE M2501 Drive Module w/Std Infeed
- Serial 17011989D-01
- Weight 240.0 Lb
- Voltage 120V/220V
- Includes Power cord included |
- Warranty AS-IS
- Dimensions 23.0in x 33.0in x 21.0in
- Shipping Type FedEx Ground
- Item Condition Good
- Manufacturing Date 2017-01-01
Product Information
Welcome scientist! Introducing the Kinematic Automation CE M2501 Drive Module w/Std Infeed, meticulously tested to specifications. This unit, with slight wear from normal use, guarantees an operational machine with a 30-day warranty. The Matrix 2501 Rotary Slitting Module skillfully cuts various rapid diagnostic test strip products and supports cutting needs from product development to production scales. With a capacity of 1,000 strips per minute, variable speed DC drive, and a blade diameter of 77.343 mm, this module is a versatile and valuable addition to your laboratory. Designed for maximum card length of 33 cm and a card thickness of 2.3 mm, this instrument is a high-throughput, low-maintenance solution for cutting a wide variety of products. The module guarantees to accurately process registered products, reflecting a modular design with quick-change slitting modules. Operating power standing at 110/220 VAC, 50/60 Hz, 10 Amp, and a blade material of hardened D2 tool steel ensures top-quality performance. Get ready for an efficient solution that ensures optimum performance with high throughput and low maintenance!
Key Features- Up to 1,000 strips per minute cutting capacity
- Accurately processes registered products with quick-change modules
- Variable speed DC drive and low maintenance
- Supports product development through to production quantities
- Modular design with a blade diameter of 77.343 mm
- Maximum card length: 33 cm
- Maximum card thickness: 2.3 mm
- Power: 110/220 VAC, 50/60 Hz, 10 Amp
- Blade material: hardened D2 tool steel
- Blade diameter: 77.343 mm
- Capacities: Up to 1,000 strips per minute (based on cards of 50 strips being fed manually)
Metric: 108.86 kg
Imperial: 240 lbs
Metric: 23 cm x 33 cm x 21 cm
Imperial: 9.06 in x 12.99 in x 8.27 in
903180
Harmonized Code Details903180 - Instruments and apparatus for measuring or checking voltage, current, resistance or power, with a recording device
