Bio Rad PowerPac Basic Power Supply

Product Information

The BIO-RAD PowerPac Basic Power Supply has been rigorously tested to specifications and found to be in good working condition. It may have some slight cosmetic blemishes due to normal use, but overall functions well. This power supply is recommended for basic applications such as submerged horizontal and mini vertical gel electrophoresis. With a compact, stackable case and timer control, it offers constant voltage or constant current output, as well as the ability to pause and resume a run. It is suitable for applications such as nucleic acid gel electrophoresis and protein gel electrophoresis. The output range is programmable from 10-300 V, fully adjustable in 1 V steps and 4-400 mA, fully adjustable in 1 mA steps. It has a maximum of 75 W. The unit also features constant voltage or constant current with automatic crossover, 4 pair recessed banana jacks in parallel, and a fully adjustable timer from 1 min to 99 hr 59 min. Additionally, it has various safety features including no-load detection, sudden load change detection, overload/short-circuit detection, and overvoltage protection. The input power is 90-120 or 198-264 VAC, 50/60 Hz, with auto switching, and the unit complies with EN-61010 and CE regulations. Overall, this BIO-RAD PowerPac Basic Power Supply is a reliable and versatile equipment for electrophoresis applications in laboratory settings.

• Compact, stackable case
• Programmable output range
• Constant voltage or constant current output
• Automatic crossover
• Timer control
• Safety features including overload/short-circuit detection
• Compliance with EN-61010 and CE regulations

• Output Range: 10-300 V, fully adjustable in 1 V steps, 4-400 mA, fully adjustable in 1 mA steps, 75 W (maximum)
• Type of Output: Constant voltage or constant current with automatic crossover
• Output Terminals: 4 pair recessed banana jacks in parallel
• Timer: 1 min-99 hr 59 min, fully adjustable
• Display: 3-digit LED
• Operating Conditions: 0-40°C, 0-95% humidity in the absence of condensation
• Safety Features: No-load detection, sudden load change detection, overload/short-circuit detection, overvoltage protection
• Input Protection: Fuse on both hot and neutral
• Input Power: 90-120 or 198-264 VAC, 50/60 Hz, auto switching
• Regulatory: EN-61010, CE

Metric: 3.63 kg
Imperial: 8 lb

Metric: 25.4 cm x 20.32 cm x 15.24 cm
Imperial: 10 in x 8 in x 6 in

9030820000

The harmonized code 9030820000 is for instruments, apparatus and models, designed for demonstrational purposes (for example, in education or exhibitions), unsuitable for other uses. This code is chosen based on the nature of the power supply as a specific instrument designed for electrophoresis applications and not for general industrial or commercial use.
