Thermo Fisher Scientific TSQ Vantage Mass Spectrometer System

Product Information

The Thermo Fisher Scientific TSQ Vantage is the top-of-the-line model of the Thermo Scientific triple stage quadrupole (TSQ) mass spectrometer product line. The TSQ Vantage incorporates state-of-the-art electronics and comprehensive diagnostics, delivering total instrument control at your fingertips. With Generation 2 (G2) ion optics, and easy-to-use Thermo Scientific Xcalibur software, it defines a new standard of excellence in bioanalytical, environmental, clinical research, and quantitative proteomic analysis. Able to simultaneously quantitate and confirm with QED-MS/MS, offering superior precision, up to 3000 SRMs definable per run, and scan speeds of up to 5000 u/s. The Mass Spectrometer provides resolution continuously adjustable to better than 0.1 Da peak width (FWHM) across the entire mass range. The unit's easy-to-use features make it a valuable tool for bioanalytical research and clinical laboratories. The TSQ Vantage plays a crucial role in environmental and proteomic research for its superior precision, industry-leading features, and easy-to-operate software, making it an asset in laboratories aiming to achieve high-quality results.

• Generation 2 (G2) ion optics for superior precision
• Simultaneous quantitation and confirmation with QED-MS/MS
• Up to 3000 SRMs definable per run
• Scan speeds of up to 5000 u/s
• Continuously adjustable resolution for better than 0.1 Da peak width

• Mass Range: - m/z 10-1500 daltons (Da) (TSQ Vantage and TSQ Vantage AM) - m/z 10-3000 Da (TSQ Vantage EMR)
• Resolution: - 7500 (FWHM) at m/z 508 of polytyrosine - Resolution is continuously adjustable to better than 0.1 Da peak width (FWHM) across the entire mass range
• Mass Stability: - Mass assignment will be within 0.050 Da over a 24-hour period. The optimum temperature of operation is between 18-21C (65-70 F).
• Dimensions: - 80cm x 58cm x 60cm
• Weight: - 160kg
• Power: - 230V 50/60Hz 15A
• Shipping Size: - Length: 85cm - Width: 63cm - Height: 65cm - Weight: 118kg

Metric: 160 kg
Imperial: 352.74 lb

Metric: 80 cm x 58 cm x 60 cm
Imperial: 31.49 in x 22.83 in x 23.62 in

9027200000

The harmonized code 9027200000 is for liquid chromatography instruments; retention mechanisms; columns, for liquid or gas-liquid chromatography. This code aligns with the nature of the TSQ Vantage Mass Spectrometer System's operation and function, making it the most suitable code.
