Thermo Dionex UltiMate 3000 LPG-3400SD Standard Quaternary Pump

Product Information

The Thermo Dionex UltiMate 3000 LPG-3400SD is a state-of-the-art Standard Quaternary Pump designed for flexibility across a broad range of analytical LC applications. With the ability to use up to four solvents, it supports pressures up to 62 MPa at flow rates of up to 10mL/min, excelling in standard LC applications while maintaining compatibility with fast UHPLC separations. This pump is ideally-suited for method development, analytical research, and routine analysis in the pharmaceutical, food and beverage, and environmental industries. It is designed to support short sub-2m particle columns for faster analysis while consuming less solvent. The UltiMate 3000 SD and Rapid Separation (RS) pumps offer similar gradient delay and extra column volumes, simplifying method transfer between different labs. Its features include a serial dual-piston operating principle, Thermo Scientific SmartFlow technology for automatic compensation of compressibility, large selection of SpinFlow mixing volumes, reliable vacuum degassing, and active rear-seal wash to maximize seal lifetime and pump uptime. The product is in good condition and comes with a 30-Day Warranty, 100% Parts and Labor.

• Supports up to four solvents for maximum flexibility in method development
• Capable of pressures up to 62 MPa and flow rates of up to 10mL/min for optimal performance
• SmartFlow technology automatically compensates for compressibility, ensuring accurate results
• Large selection of SpinFlow mixing volumes perfectly balance gradient delay volume with mixing efficiency
• Reliable vacuum degassing and active rear-seal wash maximize seal lifetime and pump uptime

• Serial dual-piston operating principle
• Wide operating flow rate range from 200L/min to 10mL/min with high flow rate accuracy
• Support of operating pressures of up to 62MPa (9,000 psi/620 bar)
• Thermo Scientific SmartFlow technology to automatically compensate for compressibility; no manual solvent setting needed
• Large selection of Thermo Scientific SpinFlow mixing volumes perfectly balance gradient delay volume with mixing efficiency
• Reliable vacuum degassing with an internal four-channel micro membrane degasser
• Active rear-seal wash to maximize seal lifetime and pump uptime

Metric: 15 kg
Imperial: 33.07 lb

Metric: 20.078751 cm x 16.141741 cm x 6.299216 cm
Imperial: 7.914882643 in x 6.3618123838 in x 2.4807194134 in

841381

841381 - Pumps for liquids, whether or not fitted with a measuring device; liquid elevators
