Thermo Fisher HPG-3400RS HPLC System Used 30-Day Warranty

Product Information

Introducing the Thermo Fisher HPG-3400RS, a biocompatible UltiMate 3000 RS series HPLC system that's found its way to our REUZEit Netherlands warehouse. This incredible system offers an industry-leading flow-pressure footprint of 103 MPa (15,000 psi) at up to 5 mL/min and 80 MPa (11,600 psi) at 8 mL/min, ensuring the highest flow precision and reliability even at elevated backpressures. While excelling in ultra high-speed and ultra high-resolution applications, it remains fully compatible with conventional analytical applications, covering the full range of HPLC, including conventional LC and UHPLC. With support for short sub-2 m particle columns for ultra-fast separations, longer columns for high-resolution UHPLC applications, and compatibility with legacy, standard LC columns and methods, the Thermo Fisher HPG-3400RS is truly versatile and cutting-edge. Notably, it integrates GLP features, enabling full support of Thermo Scientific Dionex AutoQ instrument qualification, qualification status, and system wellness monitoring. This HPLC system sports a superior serial dual-piston operating principle, outstanding flow accuracy, precision, and pulsation, along with various communication and I/O interface options. The emission sound pressure level is less than 70 dB(A) in a 1-m-distance, with compact dimensions of 16x42x51 cm and power requirements of 100-120V at 60 Hz and 200-240V at 50 Hz. The Thermo Fisher HPG-3400RS is your go-to choice for ultra high-speed, ultra high-resolution HPLC applications, backed by a 30-day warranty and 100% parts and labor coverage.

• Industry-leading flow-pressure footprint of up to 103 MPa at 5 mL/min and 80 MPa at 8 mL/min
• Versatile compatibility with various columns and methods including UHPLC applications
• GLP features for full instrument qualification and system wellness monitoring
• Superior operating principle and flow accuracy and precision
• Compact design and dual power requirements for convenience

• Operating Principle: Serial dual-piston
• Flow Accuracy: 0.1% (For BM pumps: 0.5%; For NCP-3200RS: < 0.1% RSD at 300 nL/min and 40 MPa)
• Flow Precision: < 0.05% RSD or < 0.01 min SD whichever is greater
• Pulsation: Typically: < 0.2 MPa or < 1% whichever is greater (For ISO-3100BM pump: Typically: < 0.02 MPa or < 0.1%, whichever is greater)
• GLP Features: Full support of Thermo Scientific Dionex AutoQ instrument qualification, qualification status and system wellness monitoring.
• Communications: USB for PC connection, USB hub with 3 sockets integrated, 15-pin D-sub connector for solvent rack/degasser connection.
• I/O Interface: 2 digital inputs, 2 relay outputs
• Emission Sound Pressure Level: < 70 dB(A) in 1-m-distance
• Dimensions: 16x42x51 cm (6.3x16.5x20 in)
• Power Requirements: 100-120V at 60 Hz, 200-240V at 50 Hz

Metric: 17 kg
Imperial: 37.48 lbs

Metric: 51 cm x 42 cm x 16 cm
Imperial: 20.08 in x 16.54 in x 6.3 in

9027200000

This code is used for chromatographs and electrophoresis instruments, which fits well with the HPLC system and its related functionality.
