Cavro XE 1000 Syringe Pump

Product Information

The Cavro XE 1000 is an entry-level syringe pump providing affordable pipetting performance and basic liquid handling functions for chemistry analyzers, environmental science equipment, and histology instrumentation. This versatile pump offers good value without sacrificing robustness and reliability. Its compact design with a broad dynamic range allows for easy integration into various detection devices such as plate readers and immunoassay sample preparation systems. Designed for a multitude of laboratory settings, from compact benchtop devices to lower throughput instrument requirements, the Cavro XE 1000 Pump is incredibly flexible, reliable, and offers exceptional value.

• Broad dynamic range from 5 µL to 5 mL
• Programmable plunger speeds from 2 to 60 seconds per stroke
• Supports single and multi-pump configurations
• High resolution of 1,000 increments per stroke
• Rugged, low-maintenance rack and pinion syringe drive
• Compact and lightweight design
• Flexible design with multiple valve and tubing format options
• RS-232, RS-485, or CAN interface support for up to 15 modules

• Dynamic Range: 5 µL to 5 mL
• Plunger Speed: 2 to 60 seconds per stroke
• Pump Configuration: Single or multi-pump (up to 15 modules)
• Resolution: 1,000 increments per stroke
• Syringe Drive: Rack and pinion with 30 mm travel
• Design: Compact, lightweight, anodized aluminum frame
• Interface Support: RS-232, RS-485, or CAN
• Valve and Tubing Formats: 1/4-28 or M6 options

Metric: 2.0 kg
Imperial: 4.4 lbs

Metric: 13 cm x 11 cm x 7 cm
Imperial: 5 in x 4 in x 3 in

8413811000

The harmonized code 8413811000 is used for gear pumps and hydraulic pumps, which closely aligns with the function and design of the Cavro XE 1000 Syringe Pump.
