Watson Marlow 530UN 350rpm IP66 Peristaltic Pump, 0.004ml/min to 3.5L/min
Watson Marlow
Details
-
CategoryPump
-
Dimension24.0in x 16.0in x 10.0in
-
Serial230919-356601
-
Shipping TypeFedEx Ground
-
ManufacturingDoes Not Apply
-
Voltage / Hertz120V / 50Hz UK
Description
The Watson Marlow 530UN, a robust peristaltic pump designed for precision fluid handling, offers a reliable solution for laboratory and industrial applications. Built by Watson Marlow, this model (530UN Only 350rpm IP66 us Mains Lead) is recognized for its accuracy and user-friendly interface. While the unit is brand new, it requires functionality assessment as it's currently non-functional. It offers flexible pumphead options like 520R and 520R2 for continuous tubing or 520REL to 520RET for varied pressures. It supports flow rates from 0.004ml/min to 3.5L/min, driven by a 2200:1 speed control ratio. This pump ensures isolation of fluids within the tube, maintaining product integrity. With features like a color display for visual status, IP31 and IP66 casing, dual voltage capability, and remote control via various interfaces, it stands as a versatile choice. Please note, this unit includes a power cord but not additional accessories like computers or manuals.
Key Features
- Brand: Watson Marlow
- Model: 530UN Only 350rpm IP66
- Flow rates from 0.004ml/min to 3.5L/min
- IP31 & IP66 ingress protection
- 2200:1 speed control ratio
- Flexible pumphead options
- Dual voltage 115/230V 50/60Hz
- Supports various remote interfaces
Specifications
- Maximum flow rate: 3500ml/min
- Minimum flow rate: 0.004ml/min
- Drive speed control ratio: 2200:1
- Operating temperature: 5°C to 40°C (40°F to 104°F)
- Input voltage: 115/230 V
- Ingress protection: IP31, IP66
- Compatible tubing: 0.5mm to 9.6mm
- Control options: EtherNet/IP, Profibus, Profinet, RS232, RS485, SCADA
Weight
Imperial: 32.4 Pounds
Metric: 14.7 Kilograms
Shipping Dimensions
Imperial: 28.8 lb x 19.2 lb x 12.0 lb
Metric: 73.15 cm x 48.77 cm x 30.48 cm
Harmonized Code
841360
Harmonized Code Details
841360 - Pumps for liquids, whether or not fitted with a measuring device; others. This code is applicable due to the pump's function and design, fitting the specified category criteria.
