Thermo Scientific Dionex UltiMate LPG-3400A Pump HPLC / FPLC / GC / CE, Used, 30-Day Warranty

Product Information

Introducing the Thermo Scientific Dionex UltiMate LPG-3400A Pump, the pinnacle of flexibility in solvent proportioning for UHPLC or conventional LC. Whether supporting ternary and quaternary gradients, adapting to up to four solvents at 15,000 psi, or providing a recommended flow rate range from 200L to 8.0mL/min, this pump excels in pharmaceutical, food and beverage, and environmental applications. This versatile pump also guarantees excellent flow stability, making it ideal for fast routine applications and method development.

• Supports ternary and quaternary gradients
• Adaptable to up to four solvents at 15,000 psi
• Recommended flow rate range from 200L to 8.0mL/min
• Excellent flow stability for multiple fast routine applications
• Ideal for method development in pharmaceutical, food and beverage, and environmental industries

• Flow Accuracy: 0.1%
• Flow Precision: <0.05% RSD or <0.01 min SD, whichever is greater
• Gradient Delay Volume: 325-1840 L (Default: 690 L)
• Pressure Range: 2 to 103.4 MPa up to 5 mL/min; 2 to 80 MPa up to 8 mL/min
• I/O Interfaces: 2 digital inputs, 2 relay outputs
• Proportioning Accuracy: 0.5% (full scale)
• Proportioning Precision: <0.15% SD
• PC Connection: USB for PC connection, USB hub with 3 integrated sockets
• Pressure Ripple: Typically: <0.2 MPa or <1% whichever is greater
• Max. Flow Rate: 8.0 mL/min
• Min. Flow Rate: 0.001 mL/min (Recommended: 0.1 mL/min)
• Operating Principle: Serial dual-piston

Metric: 8.618 kg
Imperial: 19 lbs

Metric: 20 cm x 16 cm x 10 cm
Imperial: 7.87 in x 6.3 in x 3.94 in

9027200000

9027200000: Scientific or laboratory equipment: Other instruments and apparatus
