Servo Bench Model High Speed Sensitive Drill Press 7000 for Precision Production Work

Product Information

Ah, the Servo Bench Model Precision High Speed Sensitive Drill Press, Model #7000. This trusty companion is a staple in any laboratory, ideal for prototype and precision production work. With its swing over table of 7", throat depth of 3-1/2", and a spindle speed range of 200 - 20,000 RPM, this drill press is truly a workhorse. The infinitely variable speed and .0002" spindle runout make it the go-to choice for demanding applications. Whether it's blind hole drilling requiring a down stop accuracy of .0001" or ensuring a chuck to table maximum distance of 6", the Model #7000 can handle the challenge with ease. Just remember, the base is not included!

• Infinitely variable spindle speeds from 200 to 20,000 RPM
• Precise .0002" spindle runout and .001" dial gauge
• Adjustable down stop accuracy of .0001" for blind hole drilling
• Maximum chuck to table distance of 6"
• Swing over the table of 7" with a 3-1/2" throat depth

• Swing over table: 7"
• Throat depth: 3-1/2"
• Spindle speeds: 200 - 20,000 RPM, infinitely variable
• Collet capacity: .0039" - .252"
• Quill travel: 1.5"
• Spindle runout: .0002"
• Dial gauge: .001"
• Adjustable down stop: .0001" for blind hole drilling
• Maximum chuck to table: 6"

Metric: 6.35 kg
Imperial: 14 lbs

Metric: 40.64 cm x 40.64 cm x 25.4 cm
Imperial: 16 in x 16 in x 10 in

846591

Machine-tools; drilling, boring, milling, threading or tapping by removing metal, other than lathes, of heading 8458
