Dionex DP-1 Detectors

Product Information

The Dionex DP-1 Detector is an outstanding device for enhancing laboratory performance, featuring innovations in all modules to improve productivity, expand capabilities, and provide superior performance. Its unique dual-piston pump, flow rate accuracy, and operational pressure make it an ideal choice for analytical chemistry and ion chromatography. The ICS-3000 Ion Chromatography System is the foundation of this impressive detector, showcasing modular versatility and superior performance in the most advanced ion chromatography system on the market.

• Dual-piston pump design for optimal performance
• Flow rate accuracy and reproducibility for precise results
• Modular versatility and superior performance enhanced by the ICS-3000 system

• Dual-piston (in series) with variable speed: 80 L per revolution
• Flow Rate Range: 0.001 to 10.0 mL/min in increments of 0.001 mL/min
• Flow Rate Accuracy and Reproducibility: 0.1% at 1.0 mL/min (typical)
• Operating Pressure: 0.1 to 35 MPa (15 to 5000 psi)
• Pressure Ripple: 1% (typical)
• Gradient Proportioning Accuracy and Reproducibility: 0.5% at 2.0 mL/min (typical)
• Number of Eluents: Four
• High Pressure Limit: 0 to 35 MPa (0 to 5000 psi) in increments of 0.1 MPa (14 psi); trips instantaneously
• Low Pressure Limit: 0 to 34 MPa (0 to 4900 psi) in increments of 0.1 MPa (14 psi)
• Vacuum Degassing Module: Built-in single-channel degas chamber with a volume of 670 L and a dual-stage diaphragm vacuum pump

Metric: 27.669 kg
Imperial: 61 lbs

Metric: 22 cm x 9 cm x 16 cm
Imperial: 8.66 in x 3.54 in x 6.3 in

9027200000

Instruments and apparatus for physical or chemical analysis
