Thermo Scientific Accela PDA Detector 190-800nm UV-Visible Wavelength Range Detector

Product Information

The Thermo Scientific Accela PDA Detector is a full-featured, time-programmable, photodiode array (PDA) detector capable of scanning the ultraviolet-visible wavelength range from 190 to 800 nm. It provides comprehensive wavelength accuracy and calibration, with advanced features such as a pre-aligned Deuterium and Tungsten light source, user-selectable rise time and scan rate, and 20-bit digital/analog conversion. The unit is robust, versatile, and can be used in various applications such as pharmaceutical analysis, food and beverage testing, and environmental monitoring. It is an essential tool in liquid chromatography systems and is well-suited for research and quality control laboratories.

• Full-featured photodiode array (PDA) detector
• Ultraviolet-visible wavelength range from 190 to 800 nm
• Pre-aligned Deuterium and Tungsten light source
• User-selectable rise time and scan rate
• Advanced 20-bit digital/analog conversion

• Wavelength Range: 190-800 nm
• Wavelength Accuracy: 1 nm at 254 nm and 640 nm
• Wavelength Resolution: 1.2 nm (512 pixel array)
• Absorbance Range: -2.0 to +4.0 AU, 20-bit resolution
• Light Source: Pre-aligned Deuterium and Tungsten lamps
• Scan Rate: User selectable: 0.5, 1, 2, 4, 5, 10, 20, 40, or 80 Hz
• The 20-bit digital/analog conversion is unattenuated at 10 mV/AU, 100 mV/AU, or 1.0 V/AU

Metric: 24.04 kg
Imperial: 53.0 lb

Metric: 20.0 cm x 14.0 cm x 8.0 cm
Imperial: 7.874 in x 5.512 in x 3.15 in

9027300000

The chosen harmonized code is for spectrometers, spectrophotometers and spectrographs using optical radiations (UV, visible, IR). This is justified by the specific capabilities and spectral range (190-800nm) of the Thermo Scientific Accela PDA Detector.
