Dionex AXP-MS Metering Pump for Mass Spectrometers (MS)

Product Information

The Dionex AXP-MS is the perfect companion to the Thermo Scientific MSQ Plus mass spectrometer (MS). Supply of cone wash solvents to keep the entrance orifice free of salt and matrix buildup for reliable operation with increased uptime. Easy delivery of the internal reservoir calibration standards to the inlet probe. The Dionex AXP-MS can also be used as a general metering device for any MS instrument when other pumping is not available or would be inconvenient. The pump offers a wide flow range from 0.01 to 1.00 mL/min at pressure ratings up to 2500 psi. Its internal pulse damper reduces pulsations while maintaining an inert flow path. The fluidic pathway is fully IC and biocompatible, manufactured with metal-free PEEK and ceramic materials. With a robust design, the self-flush head extends seal life, and the inert fluid path ensures compatibility over a wide range of solvents and chemical compounds.

• Wide flow range from 0.01 to 1.00 mL/min
• Pressure ratings up to 2500 psi
• Internal pulse damper for reduced pulsation and inert flow path
• Fully IC and biocompatible with metal-free fluidic pathway
• Robust design with self-flush head and inert fluid path

• Rated Pressure: 2500 psi
• Flow Rates: 0.01 - 1.00 mL/min
• Flow Accuracy: 3% throughout flow range
• Pressure Pulsation: 2% peak-to-peak at 100 psi, 1 mL/min with in-line pulse damper
• Flow Rate Precision: 0.5% at the calibration pressure
• Control Interfaces: Chromeleon CDS, RS-232, and relay control
• Dimensions: 6.5 x 6.5 x 10 in
• Weight: 15 lbs
• Power: 120/230 Vac 50/60 Hz
• Materials: PEEK, ceramic, and inert polymers

Metric: 5.44 kg
Imperial: 12.0 lbs

Metric: 16.51 cm x 16.51 cm x 25.4 cm
Imperial: 6.5 in x 6.5 in x 10 in

9027200000

The harmonized code 9027200000 applies to flow meters, liquid, for measuring or checking the flow or level of liquids, others.
