Fluke 910R GPS Frequency Reference Class 2 Used Laboratory Equipment

Product Information

As quirky, experienced lab scientists, we have the Fluke 910R GPS frequency reference! With precision frequency and pulse-per-second time accuracy, this class 2, used equipment is ideal for telecommunications, calibration, and test systems.

• Precision frequency and pulse-per-second time reference
• Long-term frequency stability from built-in cesium standards
• Short-term stability from built-in oven controlled crystal oscillator or rubidium oscillator

• Frequency Stability (locked to GPS 910R(GPS-Rb)): Frequency offset (24h mean) - <1x10-12, Warm up (+25C) - 20 min to lock
• Frequency Stability (Hold-over 910R(GPS-Rb)): Aging/24h - <2x10-12(typ.), Long term stability: Same as main reference
• Phase Noise - 910R: Offset Phase Noise - 1 Hz:-80 dBc/Hz (typ.), 10 Hz:-90 dBc/Hz (typ.), 100 Hz:-130 dBc/Hz (typ.)
• Reference outputs (BNC): 10MHz sine wave, 0.5V rms, 5MHz sine wave, 0.5V rms

Metric: 6.80389 kg
Imperial: 15 lbs

Metric: 53.34 cm x 20.32 cm x 43.18 cm
Imperial: 21 in x 8 in x 17 in

9030.89.92

The harmonized code 9030.89.92 classifies oscilloscopes, spectrum analyzers, and other instruments and apparatus for measuring or checking electrical quantities.
