Used Keyence SJ-F2000 Ionizing Equipment

Product Information

Greetings, scientists and innovators! Dive into the world of ionizing equipment with the Keyence SJ-F2000. This model was manufactured by Keyence and has a proud serial number of 9A120416A. Operating on a pulse AC method and an applied voltage of 7000V, this ionizer boasts an ion balance control method of I.C.C. with a static elimination time of approximately 1 second. Not only does it offer an operating distance of 50mm and a maximum wind speed of 3.5 m/s, but it also exhibits an ozone density of 0.005 ppm max. Powering this dynamic piece is the KEYENCE AC Adapter or DC Option, operating at a power voltage of 24 VDC with a current consumption of 0.9 A. With an ambient temperature range of 0 to +50°C and a relative humidity range of 35 to 65% RH, it stands as a versatile solution for tasks in environmental controls, manufacturing processes, and more. Let's bring a spark to your scientific endeavors!

• Operating distance of 50mm
• Maximum wind speed of 3.5 m/s
• Ion balance control method: I.C.C.
• Pulse AC method

• Model: SJ-F2000
• Type: 300 mm (11.81")
• Applied Voltage: 7000V
• Ion Balance: 5 V*1
• Static Elimination Time: Approx. 1 sec*2
• Maximum Wind Speed: 3.5 m/s (11.48 ft/s*1)
• Power Voltage: 24 VDC 10 %
• Current Consumption: 0.9 A
• Ambient Temperature: 0 to +50°C (32 to 122°F)
• Relative Humidity: 35 to 65%
• Voltage Application Method: Pulse AC method
• Ionization Control: I.C.C.
• Maximum Air Volume: 2.5 m3/min (88.29 CFM)
• Ozone Density: 0.005 ppm max.

Metric: 4.08233 kg
Imperial: 9 lbs

Metric: 33.02 cm x 12.7 cm x 22.86 cm
Imperial: 13 in x 5 in x 9 in

902730

9027.30.00 Ionization apparatus
