Leybold D16B Vacuum Pump Two-Stage Oil Lubricated 19.8 m3/h Ultimate Pressure
leybold
Details
-
CategoryPump
-
Dimension25.0in x 7.0in x 10.0in
-
Serial40.33846.01
-
Shipping TypeFedEx Ground
-
ManufacturingDoes Not Apply
-
Voltage / Hertz120V/220V / 50Hz/60Hz
Description
This used Leybold D16B Vacuum Pump, in very good condition, offers reliable performance with its two-stage oil-lubricated design. Suitable for laboratory and research applications, the pump handles vapor efficiently and achieves ultimate vacuum pressures of less than 2x10-3 mbar. With a displacement of 12 cfm and a pumping speed of 19.8 m3/h, it's perfect for use as a turbo pump backing pump, diffusion pump backing pump, and for vacuum ovens. Operating at voltages of 120V/220V and frequencies of 50Hz/60Hz, this durable pump can be adapted to different power settings, and its DN 25 KF inlet flange ensures secure connections.
Key Features
- Two-stage oil-lubricated design
- Ultimate vacuum pressure <2x10-3 mbar
- Displacement: 12 cfm
- Pumping speed: 19.8 m3/h
- Voltage compatibility: 120V/220V
- Inlet flange: DN 25 KF
Specifications
- Displacement: 12 cfm
- Pumping Speed: 19.8 m3/h
- Ultimate Pressure: <2x10-3 mbar
- Voltage: 120V/220V
- Hertz: 50Hz/60Hz
- Inlet Flange: DN 25 KF
Weight
Imperial: 120.0 Pounds
Metric: 54.43 Kilograms
Shipping Dimensions
Imperial: 30.0 lb x 8.4 lb x 12.0 lb
Metric: 76.2 cm x 21.34 cm x 30.48 cm
Harmonized Code
84141000
Harmonized Code Details
84141000 - Vacuum pumps; These pumps are used widely in laboratories for creating a vacuum environment as required for many scientific and research applications.
