Laird MRC300-DH2-HT-DV Thermoelectric Recirculating Chiller

Product Information

The Laird MRC300-DH2-HT-DV Thermoelectric Recirculating Chiller is a solid-state liquid chiller designed for a wide range of water solutions, with applications in medical, laser, and test laboratory environments. It provides reliable temperature control for closed loop systems, protecting the purity of the cooled product. This unit boasts a compact design, precise temperature control, reliable solid-state operation, and low noise. It is built for applications in analytical instrumentation and industrial laser cooling. The manufacturer's specifications ensure optimal performance, making it a valuable asset to any laboratory.

• Solid-state operation
• Precise temperature control
• High-density heat sinks
• Compact design

• Operating Environment Temperature Range: 4C to 45C
• Control Temperature Range (Water): 2C to 40C
• Control Temperature Range: (70/30 Water/Glycol) -12C to 40C
• Controller Accuracy: 0.16C
• Supply Voltage: 115 VACS to 230 VACS
• Current: 115 VAC (230 VAC) 8.5 Amps (4.3 Amps)
• Power Supply: 507.0 Watts
• Frequency: 50/60 Hz
• Performance Tolerance: 10%
• Fluid Capacity: 450 mL
• Maximum Flow Rate: 3.3 L/min

Metric: 18.597 kg
Imperial: 41 lb

Metric: 45.72 cm x 30.48 cm x 58.42 cm
Imperial: 18 in x 12 in x 23 in

8418690050

The harmonized code 8418690050 is for Refrigerating or Freezing Equipment; Heat pumps other than air conditioning machines of heading 8415. I used this code as it accurately represents the product's function as a recirculating chiller for cooling applications and the use of thermoelectric modules.
