Edwards RV3 A65201903 Rotary Vane Vacuum Pump

Product Information

The Edwards RV3 A65201903 rotary vane vacuum pump is renowned for its excellent ultimate vacuum pressure, high pumping speeds, superior vapor handling capabilities, and quiet operation. It sets the industry standard for R&D and scientific pumping applications. This unit has been tested to specifications and operates at a vacuum pressure of 8 microns. Its versatile performance in both high vacuum and high throughput modes makes it suitable for a range of applications including analytical instruments, electron microscopes, physics research, backing turbo pumps, leak detection, distillation, laboratory furnaces, solvent concentration, and freeze drying. Edwards RV3 is designed for optimum pumping performance, requires low maintenance, and operates quietly at 48 dBA.

• Excellent ultimate vacuum pressure
• High pumping speeds
• Superior vapor handling capabilities
• Quiet operation at 48 dBA
• Can deliver excellent ultimate vacuum in both high vacuum and high throughput modes

• Ultimate pressure: 2.0 x 10-3mbar / 1.5 x 10-3Torr
• Ultimate pressure GB I: 3.0 x 10-2mbar / 2.3 x 10-2Torr
• Ultimate pressure GB II: 1.2 x 10-1mbar / 9.1 x 10-2Torr
• Ultimate Pressure with Fomblin: 2 x 10-2mbar / 1.5 x 10-2Torr
• Max inlet pressure for water vapour: 80 mbar / 60 Torr
• Max water vapour pumping rate GB I: 60 gh-1
• Max water vapour pumping rate GB II: 220 gh-1
• Motor power 50/60Hz: 450 / 550W
• Oil capacity min/max: 0.42/0.7 litres
• Inlet flange: NW25
• Exhaust flange: NW25
• Noise level: 48 dB(A) / 50 Hz

Metric: 28.123 kg
Imperial: 62.0 lb

Metric: 43.18 cm x 20.32 cm x 27.94 cm
Imperial: 17.0 in x 8.0 in x 11.0 in

84141000

84141000 - Vacuum pumps: Rotary positive displacement pumps
