Thermo Scientific UltiMate ISO-3100SD Standard Isocratic Pump

Product Information

The Thermo Scientific UltiMate ISO-3100SD Standard Isocratic Pump, with catalog number 5040.0011, is a reliable and cost-effective solution for isocratic applications. It offers a wide flow rate range of 50L to 10mL/min and ensures high flow rate and retention time precision with its SmartFlow technology. This pump is recommended for standard isocratic applications in QA/QC laboratories and is also suitable for use as an additional pump for LC-MS systems. The pump operates on a serial dual-piston principle, supports a wide range of operating pressures, and incorporates features such as patented piston seal leakage monitoring and system wellness functions. It is robust, dependable, and offers low operating and maintenance costs.

• Wide flow rate range from 50L/min. to 10mL/min.
• SmartFlow technology for high flow rate and retention time precision
• Serial dual-piston operating principle
• Support of operating pressures of up to 62MPa (9,000 psi/620 bar)
• Low operating and maintenance costs

• Flow Accuracy: 0.1%
• Flow Precision: <0.05% RSD or <0.01 min SD, whichever is greater
• Max. Flow Rate: 10 mL/min.
• Pressure Range: 2 to 62 MPa (9000 psi)
• Type: Serial Dual-Piston Isocratic Standard Pump
• Emission Sound Pressure Level: <70 dB(A) in 1-m-distance
• For Use With (Equipment): 15-Pin D-Sub Connector for Solvent Rack/Degasser Connection
• GLP Features: Full support of Thermo Scientific Dionex AutoQ instrument qualification, qualification status and system wellness monitoring. All system parameters are logged in the Chromeleon Audit Trail
• I/O Interfaces: 2 digital inputs, 2 relay outputs
• Min. Flow Rate: 0.001 mL/min. (Recommended 0.05 mL/min.)
• No. of Eluent Lines: 1
• No. of Solvents: 1
• Operating Principle: Serial dual-piston
• PC Connection: USB for PC connection, USB hub with 3 sockets integrated
• Pressure Ripple: <0.2 MPa or <1% whichever is greater
• Solvent Degassing: External (optional)
• Unit Size: Each

Metric: 12.4 kg
Imperial: 27.3 lb

Metric: 51 cm x 42 cm x 16 cm
Imperial: 20 in x 16.5 in x 6.3 in

8413818090

8413818090: Pumps for liquids, whether or not fitted with a measuring device; liquid elevators. This code is used as the pump falls under this category based on its functionality and usage.
