Chemyx Fusion 100T Syringe Pump

Product Information

The Chemyx Fusion 100T syringe pumps are dual-channel syringe pumps designed to handle precision dosing applications effortlessly. This infusion syringe pump ensures pulseless, reproducible infusion pump rates for a wide range of analytical techniques and applications in chemical, pharma, and biotech R&D. It holds syringes from 0.5L to 60 mL and offers rates from 0.0001 L/min to 140 mL/min. The pump can be controlled via touchscreen, USB, RS232, and TTL.

• Accurate Dual-Channel Operation
• Pulseless Infusion Pump Rates
• Touchscreen, USB, RS232, and TTL Control
• Wide Range of Syringe and Flow Rate Compatibility

• Mode: Infuse Only
• Accuracy: < 0.35%
• Reproducibility: < 0.05%
• Syringe Size (Min/Max): 0.5L to 60mL
• Syringe Type: Plastic and Glass
• Minimum Flow Rate: 0.0001 L/min (with 0.5L syringe)
• Maximum Flow Rate: 90 mL/min (with 60mL syringe)
• Linear Force: 29lb (13.1kg)
• Display: 4.3 inch LCD Screen
• Connectivity: RS232 and USB-B Ports
• System Dimensions: 24 x 17 x 11 cm
• Power: 110/220 VAC
• Weight: 3kg
• Motor Drive: 0.9 Stepper Motor with Micro-stepping
• Step Resolution: 0.198 m/step
• Operating Temperature: 4C to 40C (40F to 104F)
• Storage Temperature: -10C to 70C (14F to 158F)
• Humidity: 20% to 80% RH, non-condensing

Metric: 3 kg
Imperial: 7 lbs

Metric: 24 cm x 17 cm x 11 cm
Imperial: 9.45 in x 6.69 in x 4.33 in
