Thermo Fisher LPG-3400SD Standard Quaternary Pump

Product Information

Thermo Fisher LPG-3400SD Standard Quaternary Pump Catalog number:5040.0031 Recommended Use The LPG-3400SD pump is ideally-suited for method development as well as analytical research and routine analysis in the pharmaceutical, food and beverage and environmental industries. It supports short sub-2m particle columns for faster analysis while consuming less solvent. Simple Method Transfer UltiMate 3000 SD and Rapid Separation (RS) pumps and system configurations provide similar gradient delay and extra column volumes. This simplifies the method transfer between method development labs commonly using UHPLC pumps and QC and production labs with their standard LC pump setups. Features Serial dual-piston operating principle, low-pressure gradient proportioning Wide operating flow rate range from 200L/min. to 10mL/min. with high flow rate accuracy Support of operating pressures of up to 62MPa (9,000 psi/620 bar) Thermo Scientific SmartFlow technology to automatically compensate for compressibility; no manual solvent setting needed Large selection of Thermo Scientific SpinFlow mixing volumes perfectly balance gradient delay volume with mixing efficiency Reliable vacuum degassing with an internal four-channel micro membrane degasser Active rear-seal wash to maximize seal lifetime and pump uptime Dimensions(h w d): 16 42 51 cm | 6.3 16.5 20 in Power:100120 V, 60 Hz; 200240 V, 50 Hz Flow range:0.00110.0 mL/min (0.210.0 mL/min) Max. Pressure:62 MPa Solvent Degassing:Built-in, 4 Channels Weight:13.5 kg (29.8 lbs) I/O Interface: 2 digital inputs, 2 relay outputs.

• Serial dual-piston operating principle
• Support of operating pressures of up to 62MPa
• Automatic compensation for compressibility with SmartFlow technology
• Reliable vacuum degassing with four-channel micro membrane degasser
• Flow range from 0.00110.0 mL/min

• Serial dual-piston operating principle
• Low-pressure gradient proportioning
• Wide operating flow rate range from 200L/min. to 10mL/min.
• Support of operating pressures of up to 62MPa (9,000 psi/620 bar)
• SmartFlow technology for automatic compensating for compressibility
• Large selection of SpinFlow mixing volumes for gradient delay balancing
• Reliable vacuum degassing with an internal four-channel micro membrane degasser
• Active rear-seal wash to maximize seal lifetime and pump uptime
• Dimensions: 16cm x 42cm x 51cm
• Power: 100-120V, 60Hz; 200-240V, 50Hz
• Flow range: 0.001-10.0 mL/min (0.2-10.0 mL/min)
• Max. Pressure: 62 MPa
• Solvent Degassing: Built-in, 4 Channels
• Weight: 13.5 kg (29.8 lbs)
• I/O Interface: 2 digital inputs, 2 relay outputs

Metric: 13.5 kg
Imperial: 29.8 lb

Metric: 51 cm x 42 cm x 16 cm
Imperial: 20 in x 16.5 in x 6.3 in
