Leybold ECODRY 65 Plus Vacuum Pump

Product Information

Meet the Leybold Cascadion ECODRY 65 Plus Pump, tested to reach an impressive 0.0587 mBar. This dry-compression multi-stage Roots vacuum pump is perfect for quiet and clean environments like research and analysis laboratories. The ECODRY plus delivers stable vacuum performance for many years without maintenance, thanks to the integrated features like low noise levels, clean and oil-free operation, and ease of use. With a quiet noise level lower than 52 dB(A) and compact design powered by regular single-phase sockets, this pump is the ideal choice for a quiet and reliable vacuum performance.

• Integrated acoustic insulation and silencer for low noise levels
• Oil-free suction chamber and wear-free operation for a clean environment
• Compact and easy to reposition with integrated wheels

• Manufacturer: Leybold
• Model: ECODRY 65 Plus
• Pumping Speeds: 32.0 CFM, 907 L/min, 15.1 L/s, 54.4 m3/hr
• Max Water Vapor Pumping Rate (with gas ballast): 500 g/hr
• Ultimate Pressure Total With Gas Ballast: 3.00 x 10-2hPA, 3.00 x 10-2mbar, 3.00 Pa, 2.30 x 10-2Torr
• Cooling Method(s): Convection
• Motor Power: 0.60 kW
• Inlet Flange: KF40
• Noise db(A): 52.0
• Compression Stages: 7
• Weight: 43.0 kg
• Dimensions: 600 x 320 x 298 mm
• Lubrication Type: Dry
• Vacuum Range: Medium Vacuum (1 - 10-3Torr)
• Technology Type: Multi-Stage Roots

Metric: 43.0 kg
Imperial: 94.8 lbs

Metric: 600 cm x 320 cm x 298 cm
Imperial: 236.22 in x 125.98 in x 117.32 in

841410

841410 - Vacuum pumps, <50 m³/hr
