Chemyx Fusion 101 Syringe Pump

Product Information

The Fusion 101 Syringe Pump by Chemyx is a high-performance, low-cost syringe pump designed for use in synthetic chemistry, electro-spinning, drug infusion, and ESI microliter injections. The Fusion 101 performs the most precision dispensing activities, featuring smooth, pulseless flow, high accuracy at low flow rates, and pumps for automatic calibration. Its bright LCD, easy-to-use menu interface, and smart operation make it a versatile tool in laboratory settings.

• Smooth, pulseless flow
• High accuracy at low flow rates
• Automatic calibration
• Bright LCD and easy-to-use menu interface
• Smart operation

• Mode: Infuse Only
• Accuracy: < 0.35%
• Reproducibility: < 0.05%
• Syringe Size: 0.5L to 60mL
• Syringe Type: Plastic and Glass
• Minimum Flow Rate: 0.0001 L/min
• Maximum Flow Rate: 90 mL/min
• Linear Force: 29lb (13.1kg)
• Display: 4.3 inch LCD Screen
• Connectivity: RS232 and USB-B Ports
• System Dimensions: 9.5 x 6.8 x 4.4 inches (24 x 17 x 11 cm)
• Power: 110/220 VAC
• Weight: 7lbs (3kg)
• Motor Drive: 0.9 Stepper Motor with Micro-stepping
• Step Resolution: 0.198 m/step
• Operating Temperature: 4C to 40C (40F to 104F)
• Storage Temperature: -10C to 70C (14F to 158F)
• Humidity: 20% to 80% RH, non-condensing

Metric: 3 kg
Imperial: 7 lbs

Metric: 24 cm x 17 cm x 11 cm
Imperial: 9.5 in x 6.8 in x 4.4 in
