Agilent G1316A HPLC Column Compartment

Product Information

The Agilent G1316A Colcom column compartment features two heat exchangers for solvent pre-heating, automated column identification module and CAN cable. With a temperature range of 10 below ambient to 80°C and a temperature stability of 0.15°C, it has a column capacity of three 30 centimeter columns and can utilize a temperature accuracy of 0.8°C. The warm up/cool down time is 5 mins from ambient to 40°C. Peltier heating and cooling allows for high heating and cooling speeds for maximum flexibility and stability. This used column compartment is designed for HPLC applications and is in working condition. Typical applications include pharmaceutical analysis, separation and quantification of drugs, and environmental testing.

• Two heat exchangers for solvent pre-heating
• Automated column identification module
• CAN cable connectivity
• Temperature range of -10°C to 80°C
• Column capacity for three 30cm columns
• Peltier heating and cooling
• Working condition

• Temperature Range: -10°C to 80°C
• Temperature Stability: 0.15°C
• Column Capacity: Three 30cm columns
• Temperature Accuracy: 0.8°C
• Warm Up/Cool Down Time: 5 minutes from ambient to 40°C
• Heating/Cooling Technology: Peltier
• Intended Use: HPLC applications
• Applications: Pharmaceutical analysis, drug separation, environmental testing

Metric: 10.0 kg
Imperial: 22.0462 lb

Metric: 43.0 cm x 35.0 cm x 15.0 cm
Imperial: 16.93 in x 13.78 in x 5.91 in

90272000

90272000 - Chromatographs and electrophoresis instruments; other instruments and apparatus,
