Dionex ED40-1 Electrochemical Detector Analytical Laboratory Use
Dionex
Details
-
CategoryAnalytical
-
Dimension16.0in x 9.0in x 6.0in
-
Serial01090569
-
Shipping TypeFedEx Ground
-
ManufacturingDoes Not Apply
-
Voltage / Hertz120V/220V / 50Hz/60Hz
Description
The Dionex ED40-1 Electrochemical Detector by Dionex delivers reliable performance for laboratory analyses. This system measures current from the application of potential across electrodes in flow-through cells, offering valuable readings for analytical chemists to determine the components and quantities in solutions. Ranges include 0.01 S to 3000 S full scale for conductivity and a temperature compensation range from 0.0 to 3.0% per C for conductivity. Made with 316 stainless steel cell bodies (amperometry) and working electrodes composed of gold, silver, platinum, and glassy carbon, this detector ensures high-quality, accurate results. Front panel controls enable easy local operation, with remote control of functions available via TTL or Relay contacts. This used model is in very good condition and fully functional, supporting laboratory tasks efficiently at pressures up to 300 psi for conductivity functions.
Key Features
- Measures current from potential across electrodes
- Supports conductivity and amperometry analyses
- 316 stainless steel construction for durability
- Wide conductivity range of 0.01 S to 3000 S
- Temperature compensation from 0.0 to 3.0% per C
- Local and remote operation with easy controls
- Supports pressures up to 300 psi in conductivity
Specifications
- Conductivity Range: 0.01 S to 3000 S, full scale
- Integrated Amperometry Range: 50 pC to 200 C
- DC Amperometry Range: 50 pA to 300 A
- Temperature Compensation: 0.0 to 3.0% per C (Conductivity)
- Cell Drive: Variable 8 kHz square wave (Conductivity), 2.04 V (DC and Integrated Amperometry)
- Local Operation: Front panel controls and display status
- Remote Operation: Control of 4 of 7 functions via TTL or Relay contacts
- Cell Body: PEEK
- Active Volume: 1.0 L (Conductivity), 0.2 L (Amperometry)
- Maximum Pressure: 2.0 mPa (300 psi, Conductivity), 0.7 mPa (100 psi, Amperometry)
- Electrodes: 316 stainless steel; Working Electrodes: Gold, Silver, Platinum, Glassy Carbon
Weight
Imperial: 21.6 Pounds
Metric: 9.8 Kilograms
Shipping Dimensions
Imperial: 19.2 lb x 10.8 lb x 7.2 lb
Metric: 48.77 cm x 27.43 cm x 18.29 cm
Harmonized Code
9027.80.50
Harmonized Code Details
The code 9027.80.50 under HS recognizes equipment and instruments designed for laboratory analysis and measurement which includes instruments like electrochemical detectors. The choice is justified due to its usage in analytical and lab settings.
