Thermo Accela PDA Detector 190-800nm 20-Bit Digital Conversion Used
Thermo Scientific
Details
-
CategoryHPLC / FPLC / GC / CE
-
Dimension20.0in x 14.0in x 8.0in
-
Serial800153
-
Shipping TypeFedEx Ground
-
ManufacturingDoes Not Apply
-
Voltage / Hertz120V/220V / 50Hz/60Hz
Description
Experience the precision and reliability of the Thermo Accela PDA Detector. This used benchtop unit is a sophisticated addition to the Accela liquid chromatography system, designed to scan the ultraviolet-visible wavelength range from 190 to 800 nm with an effective resolution of 1.2 nm. Utilizing a 20-bit digital conversion, it offers scanning capabilities at adjustable rates of 0.5 to 80 Hz. The unit includes a dual-light source and is ready for integration via Ethernet to a data system computer with Xcalibur or ChromQuest software, making it ideal for comprehensive spectral data acquisition. Rated in very good condition, the detector comes with a pre-aligned deuterium and tungsten light source, offering absorbance range from -2.0 to +4.0 AU. The system offers user selectable rise times and scan rates for versatile application. It delivers consistent performance with minimal noise and drift at stable temperatures, ensuring accurate results for liquid chromatography applications. This model ensures excellent wavelength accuracy, resolution, and has been tested for functionality to support rigorous lab environments.
Key Features
- Ultraviolet-visible range of 190 to 800 nm
- 1.2 nm wavelength resolution
- 20-bit digital conversion
- Adjustable scan rates from 0.5 to 80 Hz
- Ethernet compatible for data integration
- Dual-light source: deuterium and tungsten
- High absorbance range of -2.0 to +4.0 AU
Specifications
- Wavelength Range: 190-800 nm
- Resolution: 1.2 nm (512 pixel array)
- Absorbance Range: -2.0 to +4.0 AU
- Scan Rate: User selectable up to 80 Hz
- Light Source: Pre-aligned Deuterium and Tungsten lamps
- Wavelength Accuracy: 1 nm at certain calibrations
- Dimensions: 20 mm cell/2 L LightPipe or 50 mm cell/10 L LightPipe
- Analog Outputs: 20-bit digital/analog conversion
- Diodes: 512 with 1.2 nm spacing
Weight
Imperial: 51.6 Pounds
Metric: 23.41 Kilograms
Shipping Dimensions
Imperial: 24.0 lb x 16.8 lb x 9.6 lb
Metric: 60.96 cm x 42.67 cm x 24.38 cm
Harmonized Code
902780
Harmonized Code Details
902780: Instruments and apparatus for physical or chemical analysis, designated for chromatographic/mass spectrometric systems, matches the equipment's usage and technical features as a liquid chromatography detector.
