APC SYPM4KP Power Module 4kVA 208V Double Conversion On-Line Protection
APC
Details
-
CategoryComputer / IT
-
Dimension12.0in x 35.0in x 17.0in
-
SerialAD2215210518
-
Shipping TypeFedEx Ground
-
ManufacturingDoes Not Apply
-
Voltage / Hertz208V / Does Not Apply
Description
This APC SYPM4KP Symmetra LX 4kVA Power Module, model LX 4KVA POW MOD 208V, provides high-density double-conversion on-line power protection with scalable runtime, perfect for demanding environments. Engineered for business continuity, it features a modular, redundant architecture and field-swappable components, ensuring every part can be upgraded quickly. The unit supports a flexible design that accommodates space constraints while providing substantial runtime and power capacity. It operates at catapults at 200V/208V with other voltage compatibility and can dynamically configure outputs for 120/208 or 120/240 voltage. Its key features include an efficiency rating at full load, input frequency auto-sensing capabilities, and a high input power factor. The unit is silver, non-rack-mountable, has standards certification including CSA and UL 1778, and operates in temperatures from 32 to 104°F. The compact dimensions, including a height of 5.91 inches, make it a suitable choice where space is limited.
Key Features
- Modular, redundant architecture
- Double-conversion on-line power protection
- Scalable runtime and power capacity
- Field-swappable components
- Efficiency at full load with power factor of 0.98
- Operates with input voltage of 200V and 208V
Specifications
- Main Input Voltage: 200V, 208V
- Output Voltage: Configurable for 120/208 or 120/240
- Max Configurable Power: 3200W
- Rated power in VA: 4000VA
- Output connector type: Hard Wire 4-wire (2PH+N+G)
- Topology: Double Conversion Online
- Wave type: Sine wave
- Input Frequency: 45-65 Hz auto-sensing
- Efficiency at Full Load: 155-276V
- Harmonic Distortion: <5% at full load
- Product Certifications: CSA, FCC Part 15 class A, UL 1778
- Environmental operating temperature: 32…104 °F
Weight
Imperial: 48.0 Pounds
Metric: 21.77 Kilograms
Shipping Dimensions
Imperial: 14.4 lb x 42.0 lb x 20.4 lb
Metric: 36.58 cm x 106.68 cm x 51.82 cm
Harmonized Code
850440
Harmonized Code Details
The code 850440 is used for 'Static converters; uninterruptible power supplies', applicable due to the item's function as a power module providing uninterruptible power supplies.
