Tektronix TDS744A Digitizing 4-Channel Oscilloscope GPIB 500MHz Bandwidth
Tektronix
Details
-
CategoryTesting Equipment
-
Dimension17.0in x 17.0in x 7.0in
-
SerialB020810
-
Shipping TypeFedEx Ground
-
ManufacturingDoes Not Apply
-
Voltage / Hertz120V / 50Hz/60Hz
Description
The Tektronix TDS744A Digitizing Oscilloscope is a used, good-condition 4-channel instrument, ideal for diverse test and measurement applications, with a 500MHz bandwidth and a sample rate reaching 2 GS/s. This versatile scope features a record length of up to 50,000 points per channel. It's fully programmable, incorporating GPIB, RS-232, and Centronics I/O ports for ample connectivity. Notable functionalities include InstaVu acquisition mode, pulse width triggering, and up to 13-bit resolution with the Hi-Res mode. The oscilloscope also supports automated measurements and waveform pass/fail testing. Cosmetic wear is minimal, see attached photos for details. Options integrated in this model include RS-232/Centronics ports, a 3.5-inch floppy disk drive, and advanced DSP math, enhancing its utility in advanced digital and analog design as well as R&D activities.
Key Features
- 500MHz bandwidth
- 4 channels
- Sample rate up to 2 GS/s
- 50,000 points record length per channel
- GPIB, RS-232, Centronics ports
- InstaVu acquisition mode
- Pulse width triggering
Specifications
- Bandwidth: 500 MHz
- Channels: 4
- Sample Rate: Up to 2 GS/s
- Record Length: 50,000 points per channel
- Vertical Resolution: 8-bit (up to 13-bit with Hi-Res mode)
- Vertical Sensitivity: 1 mV/div to 10 V/div
- Options: 13 (RS-232/Centronics), 1F (3.5-inch floppy disk), 2F (Advanced DSP math)
- Triggering: Pulse Width, Runt, Pattern, State, Setup and Hold Violation, Slew Rate
- Display: High-resolution color monitor
- Monitor Output: VGA output to external monitor
Weight
Imperial: 37.2 Pounds
Metric: 16.87 Kilograms
Shipping Dimensions
Imperial: 20.4 lb x 20.4 lb x 8.4 lb
Metric: 51.82 cm x 51.82 cm x 21.34 cm
Harmonized Code
903039
Harmonized Code Details
The harmonized code 903039 corresponds to oscilloscopes and similar instruments. Given the Tektronix TDS744A is a digitizing oscilloscope, this category reflects its primary function as a testing and measuring instrument.
