MasterFlex 77201-60 Pump Head Easy-Load II 4-Roller Adjustable Occlusion
MasterFlex
Details
-
CategoryPump
-
Dimension5.0in x 4.0in x 5.0in
-
Serial1022010113
-
Shipping TypeFedEx Ground
-
ManufacturingDoes Not Apply
-
Voltage / HertzDoes Not Apply / Does Not Apply
Description
The MasterFlex 77201-60 Easy-Load II Pump Head offers innovative design and functionality, ideal for precision fluid handling applications. Manufactured by MasterFlex, this pump head features an automatic tubing retention system, allowing for easy tubing changes without detaching the head from the drive. This model is engineered with a four-roller rotor, enhancing pressure performance and mechanical stability while minimizing pulsation. Notable for its stackable design, the pump head supports multichannel applications, optimizing space utilization in various setups. The adjustable occlusion capability allows users to balance between higher pressure and longer tubing life. Designed to accommodate L/S Precision pump tubing sizes, the pump head achieves a maximum flow rate of 2300 ml/min. With housing made of PPS and a stainless steel rotor, it ensures durability and efficiency. This equipment, classified as turnkey, is fully functional and ready for immediate use.
Key Features
- Automatic tubing retention system
- Four-roller rotor design
- Adjustable occlusion for pressure control
- Stackable for multichannel applications
- Compatible with L/S Precision tubing
Specifications
- Model: 77201-60
- Rollers: 4
- Max. flow rate: 2300 ml/min
- Housing material: PPS
- Rotor Material: Stainless Steel
- Dimensions: Height 121 mm, Length 82 mm, Width 127 mm
- Gear ratio: 1:1
- No. of Channels: 1
- Occlusion: Adjustable
- Optimum RPM range: 0.02 - 600 rpm
- Pump series: L/S
- Suction lift: 8.8 m (29 ft.)
- Tubing retention: Automatic
- Tubing sizes accepted: L/S 13, L/S 14, L/S 16, L/S 25, L/S 17, L/S 18
- Volume per revolution with L/S 13 tubing: 0.06 ml
- Volume per revolution with L/S 14 tubing: 0.21 ml
- Volume per revolution with L/S 16 tubing: 0.8 ml
- Volume per revolution with L/S 17 tubing: 2.8 ml
- Volume per revolution with L/S 18 tubing: 3.8 ml
- Volume per revolution with L/S 25 tubing: 1.7 ml
Weight
Imperial: 6.0 Pounds
Metric: 2.72 Kilograms
Shipping Dimensions
Imperial: 6.0 lb x 4.8 lb x 6.0 lb
Metric: 15.24 cm x 12.19 cm x 15.24 cm
Harmonized Code
8413.91
Harmonized Code Details
This code is used for parts of pumps, centering mostly on parts specifically used in apparatus designed to move fluids, which fits the profile of the MasterFlex pump head.
