Masterflex 77201-60 Pump Head L/S Precision Tubing 2300 ml/min Stackable
MasterFlex
Details
-
CategoryPump
-
Dimension5.0in x 4.0in x 5.0in
-
Serial1022011274
-
Shipping TypeFedEx Ground
-
ManufacturingDoes Not Apply
-
Voltage / HertzDoes Not Apply / Does Not Apply
Description
The Masterflex 77201-60 Easy-Load II Pump Head, manufactured in the United States, is a versatile and efficient solution for laboratory fluid handling needs. This new system is fully functional, featuring a four-roller rotor that enhances pressure performance and mechanical stability, significantly reducing pulsation. The unit's design includes automatic tubing retention for easy use with multiple L/S Precision tubing sizes, with a maximum flow rate of 2300 ml/min. Compact and stackable, it accommodates multichannel applications, perfect for laboratories requiring space-efficient yet robust pumping solutions. The pump head is made of durable PPS housing and stainless steel rotor material, ensuring long-term reliability. With an optimum RPM range of 0.02 - 600 rpm and adjustable occlusion, it easily adapts to varying pressure requirements.
Key Features
- Four-roller rotor for improved performance
- Automatic tubing retention
- Stackable for multichannel applications
- Compact design for space efficiency
- Adjustable occlusion for pressure control
Specifications
- Model: 77201-60
- Max. Flow Rate: 2300 ml/min
- Housing Material: PPS
- Rotor Material: Stainless Steel
- Height: 121 mm (4.75")
- Length: 82 mm (3.25")
- Width: 127 mm (5")
- Gear Ratio: 1:1
- Number of Channels: 1
- Occlusion: Adjustable
- Optimum RPM Range: 0.02 - 600 rpm
- Suction Lift: 8.8 m (29 ft.)
- Tubing Retention: Automatic
- Tubing Sizes Accepted: L/S 13, 14, 16, 17, 18, 25
Weight
Imperial: 6.0 Pounds
Metric: 2.72 Kilograms
Shipping Dimensions
Imperial: 6.0 lb x 4.8 lb x 6.0 lb
Metric: 15.24 cm x 12.19 cm x 15.24 cm
Harmonized Code
8413.81.0050
Harmonized Code Details
Centrifugal pumps other than submersible, with capacities not exceeding 5 m³/h. Suitable due to its characteristics and application in precise laboratory fluid handling.
