Thermo Vanquish H Column Compartment
Thermo Scientific
Details
-
CategoryHPLC / FPLC / GC / CE
-
Dimension51.0cm x 46.0cm x 18.0cm
-
SerialDoes Not Apply
-
Shipping TypeFedEx Ground
-
Manufacturing2018-11-28
-
Voltage / Hertz100-240 / 50Hz/60Hz
Description
The Thermo Vanquish Column Compartment H, manufactured in 2018, is an essential component for high-performance UHPLC systems, ensuring precise temperature control for effective separation processes. Compatible with the Vanquish Flex and Horizon UHPLC systems, it accommodates up to two columns with a maximum length of 300 mm (including pre-heater) for optimal performance. The device offers a wide temperature range from 5°C to 120°C, with still-air and forced-air thermostatting modes for accuracy and efficiency under different operational conditions. Advanced features like active eluent preheating and post-column cooling enhance separation control, while options for advanced workflows including Tandem LC and 2D-LC are supported with up to two additional switching valves. The unit shows signs of cosmetic wear but powers on and runs basic tests, with no known functionality issues.
Key Features
- Wide temperature range from 5°C to 120°C
- Compatible with Vanquish Flex and Horizon systems
- Column capacity: max 2 columns with up to 300 mm length
- Still-air and forced-air thermostatting options
- Supports advanced workflows: Tandem LC, 2D-LC
Specifications
- Temperature control range: 5°C to 120°C
- Accommodates up to two columns: Max length 300 mm
- Supports still-air and forced-air thermostatting
- Active eluent preheating and post-column cooling
- Compatible with Vanquish Flex and Horizon UHPLC
Weight
Imperial: 39.6 Pounds
Metric: 17.96 Kilograms
Shipping Dimensions
Imperial: 24.0 lb x 21.6 lb x 8.4 lb
Metric: 60.96 cm x 54.86 cm x 21.34 cm
Harmonized Code
90279050
Harmonized Code Details
90279050 is used for parts and accessories of instruments and apparatus for physical or chemical analysis. The code is appropriate due to the specialized nature of the column compartment in aiding UHPLC processes, which involve precise temperature regulation for analysis.
