Powervar Security Plus II - Battery Backup Power Model

Product Information

The Powervar Security Plus II is an advanced power protection system designed for mission-critical applications. It features industry-leading capacity, efficiency, and user-friendly features within a sleek, space-saving footprint, ensuring seamless performance and a positive return on investment. This series is equipped with Powervar's proven low impedance isolation transformer technology and unprecedented load inrush capacity, allowing for quick and easy on-site connection and serviceability. The Security Plus II offers tight voltage regulation, low input THDi, high load inrush capacity, and integrated SNMP card slot. With sizes ranging from 2 kVA to 10 kVA and all models CE marked, this system is a reliable and cost-effective power protection solution.

• Low impedance isolation transformer technology
• Unprecedented load inrush capacity
• Integrated SNMP card slot
• ECO mode for energy efficiency
• Proven reliability and performance

• Model: PowerVar Ametek Security Plus (UPS) ABCDEF6000-22BBP-ADV-6000-PSW-ONL
• Power Rating (VA/Watts): 6000 / 5400
• Type: Online (Double Conversion) With Isolation
• Inverter Waveform: Pure Sine Wave
• Transfer Time: 0 ms (Always Engaged)
• Frequency: 50/60 Hz
• Input Voltage: 200, 208, 220, 230, 240
• Output Voltage: 120, 200, 208, 220, 230, 240
• Input Voltage Range: 140 To 276 Volts
• Output Regulation (On Mains): 3%
• Output Regulation (On Battery): 3%
• Backup Time at Full Load: >5 Minutes
• Recharge Time: 8 Hours To 90%
• Batteries: 16x 12 Volt 7 Amp Hours
• Input Plug: Hardwire
• Output Receptacles: Hardwire
• Temperature (Operating): 0 to 40°C (32 to 104°F)
• Humidity (Operating): 5% to 90% Non-Condensing
• Altitude (Maximum Operating): 2,000m (6,500 ft)
• Shipping Size: Length 96cm, Width 44cm, Height 107cm, Weight 178kg

Metric: 178 kg
Imperial: 392.42236 lb

Metric: 96 cm x 44 cm x 107 cm
Imperial: 37.795296 in x 17.322844 in x 41.732306 in
