Agilent G1330B HPLC Fraction Collector Peltier Heat Exchanger Temp Control
Agilent
Details
-
CategoryHPLC / FPLC / GC / CE
-
Dimension43.0cm x 34.0cm x 15.0cm
-
SerialDE13211327
-
Shipping TypeFedEx Ground
-
ManufacturingDoes Not Apply
-
Voltage / Hertz120V/220V / 50Hz/60Hz
Description
The Agilent G1330B Thermostat, part of the Agilent 1100 Series, is designed to precisely regulate temperatures for High-Performance Liquid Chromatography (HPLC) systems and fraction collectors. This unit features Peltier-controlled heat exchangers to maintain consistent thermal conditions. Air is drawn from above the sample vial tray, cooled or heated by the thermostat module, and redirected, ensuring precise adherence to set temperatures. Despite minor cosmetic defects that don't impede function, this used unit offers high value once operational. Key specifications include a power consumption of 260 VA, automatic voltage selection (100-120 or 220-240 VAC), and dual frequency capability (50 or 60 Hz). With its compact dimensions of 14 cm x 34.5 cm x 43.5 cm and a weight of approximately 20.7 kg, the G1330B integrates seamlessly into existing setups. Made in Germany by Agilent, this equipment is indicative of robust engineering and reliability in laboratory settings.
Key Features
- Designed for HPLC systems
- Peltier-controlled heat exchangers
- Automatic voltage selection
- Compact and space-efficient
- Used condition with minor functional defects
Specifications
- Weight: 20.7 kg (45.6 lbs)
- Dimensions: 140 x 345 x 435 mm (5.5 x 13.5 x 17 inches)
- Line Voltage: 100-120 or 220-240 VAC, automatic selection
- Line Frequency: 50 or 60 Hz
- Power Consumption: Autosampler - 300 VA, ALS Thermostat - 260 VA
- Peltier-controlled heat exchangers for temperature control
Weight
Imperial: 55.56 Pounds
Metric: 25.2 Kilograms
Shipping Dimensions
Imperial: 20.31 lb x 16.06 lb x 7.09 lb
Metric: 51.59 cm x 40.79 cm x 18.01 cm
Harmonized Code
9027.20.10
Harmonized Code Details
9027.20.10 Instruments and appliances for physical or chemical analysis: Chromatographs and electrophoresis instruments. This code is suitable due to the HPLC application of controlling temperature within chromatographic settings.
