Mokon Circulating Water Temperature Control System DT4C24AHC

Product Information

Mokon - Hydrothermal DT4309AFJ Circulating Water Temperature Control System. The Hydrotherm circulating water temperature control system is designed to enhance accuracy, operational reliability, and maximize output. This system is expertly engineered using top-quality non-ferrous and stainless steel materials, ensuring durability and preventing water contamination. The unique design boasts a stainless steel pump, composite impeller, silicon-carbide seal, and stainless steel components throughout, providing unparalleled control efficiency and accuracy, reducing downtime, and lowering operating costs. This compact, portable system features advanced heating canister with a turbulent flow diverter, leading to higher velocity, maximum turbulence, and lower scale build-up that can cause heater burn-out. The system also includes safety shut-off switches, pressure relief valve, solenoid cooling valve, automatic air purge, suction and discharge pressure gauges, and a powder-coated finish. It's a go-to choice for precise and accurate temperature control and surpasses competitive systems with its stainless steel components.

• Advanced heating canister with turbulent flow diverter
• Stainless steel pump, composite impeller, and silicon-carbide seal
• Compact and portable design
• Automatic air purge and pressure relief valve
• Powder-coated finish for added durability
• cULus 508A labeled electrical sub-panel

• Stainless steel wetted surfaces to prevent rust and water contamination
• Forced flow path over heating elements for higher velocity and maximum turbulence
• Controlled single zone configurations
• Low pressure and high-temperature safety shut-off switches
• Removable panel for easy access to the heater
• Heavy-duty removable casters for portability

Metric: 90.72 kg
Imperial: 200 lbs

Metric: 40 cm x 20 cm x 30 cm
Imperial: 15.75 in x 7.87 in x 11.81 in

841989

Machinery, plant or laboratory equipment, whether or not electrically heated, for the treatment of materials by a process involving a change of temperature
