Biotek Instrument Precision NanoAssemblr Nanosystem for Nanoparticle Prototyping
Biotek
Details
-
CategoryBioprocessing
-
Dimension13.0in x 9.0in x 15.0in
-
SerialNA-1.5-48
-
Shipping TypeFedEx Ground
-
ManufacturingDoes Not Apply
-
Voltage / Hertz120V / 60Hz US
Description
The Biotek Instrument Precision NanoAssemblr Nanosystem is designed for rapid prototyping of novel nanoparticles, addressing challenges in nanoparticle creation with its proprietary microfluidics technology. This benchtop system allows for precise mixing of nanoparticle components, enabling users to tune sizes ranging from approximately 20 to 120+ nm through controlled process parameters such as mixing ratios and flow rate. Capable of 30+ formulations daily, it supports efficient development in fields like protein delivery, nucleic acid delivery, and targeted drug delivery. With flow rates between 2 to 12 mL/min and temperature control from 20 to 70°C, this system ensures precise results with minimal waste. The condition is reported as good, with some wear from use, but functional testing is limited. Power cords are included. This system can accelerate research in nanomedicine development through its flexibility and fast operation, making it an essential tool for scientists focusing on advanced nanoparticle design.
Key Features
- Proprietary microfluidics for quick mixing
- Tunable particle sizes (~20 to 120+ nm)
- Produces 30+ formulations per day
- Flow rates of 2 to 12 mL/min
- Temperature control: 20 - 70°C
- Compatible with 1, 3, 5, 10 ml BD Luer-Lok or Slip-Tip syringes
- Max volume per run: 15 mL
- Laminar fluid mixing properties
Specifications
- Flow Rates: 2 to 12 mL/min
- Temperature Control: 20 - 70 °C (with heating block)
- Syringe Compatibility: 1, 3, 5, 10 ml BD Luer-Lok or Slip-Tip
- Max Volume per Run: 15 mL
- Min Recommended Volume per Run: 1 mL
- Fluid Mixing Time: <3 ms
- Fluid Mixing Properties: Laminar
- Waste Collection: 15 mL Falcon Conical Tubes
- Electrical Power: 100 - 240 VAC, 1.2 A (Max.)
- Heating Controller Power: 100 - 240 VAC, 0.58 A (Max.)
Weight
Imperial: 10.8 Pounds
Metric: 4.9 Kilograms
Shipping Dimensions
Imperial: 15.6 lb x 10.8 lb x 18.0 lb
Metric: 39.62 cm x 27.43 cm x 45.72 cm
Harmonized Code
902780
Harmonized Code Details
902780 - Instruments and apparatus for physical or chemical analysis. This code fits as the product is related to nanoparticle systems used for chemical research and analysis.
