Wastech SSPLS-30-005 Solvent Dispense Systems 30 Gallon Stainless Steel
Wastech
Details
-
CategoryPump
-
Dimension55.0in x 32.0in x 81.0in
-
Serial171-288-507
-
Shipping TypeFreight
-
Manufacturing2018-01-01
-
Voltage / Hertz120V / Does Not Apply
Description
The Wastech Model SSPLS-30-005 is a used Solvent Dispense System manufactured in 2018, designed for safe and efficient handling of solvents in environments where gravity drainage isn't feasible. Constructed from corrosion-resistant 316 stainless steel, this system features a 30-gallon tank with a 1/2'' pump size connection. It is optimally engineered for Class 1 Division 1 hazardous environments, offering automatic change-over capabilities between two solvent drums to prevent interruptions during the dispense process. The lift station includes a host of safety features such as an intrinsically safe multipoint level switch assembly, a high-high level switch to trigger alarms, and a fire-rated enclosure with leak detection sensors. The system operations are controlled by Wastech's industrial AOD pump control panels, with options for remote or central panel instances via PLC controls, making it highly adaptable. Please note that power/data cables and computer/software are not included.
Key Features
- Corrosion-resistant 316 stainless steel construction
- Class 1 Division 1 rated for hazardous environments
- 30-gallon tank capacity with 1/2'' pump connection
- Automatic drum change-over
- Intrinsically safe multipoint level switch assembly
- Fire-rated enclosure with leak detection sensors
Specifications
- Tank Volume: 30 gallons
- Material: 316 Stainless Steel
- Pump Size: 1/2'' Connection
- Configuration: Simplex (one pump) or Duplex (two pumps)
- Control: Wastech industrial AOD pump control panels (IAPCP)
- Ratings: Class 1 Division 1 for hazardous locations
- Safety Features: High-high level switch alarm, leak detection
Weight
Imperial: 1800.0 Pounds
Metric: 816.47 Kilograms
Shipping Dimensions
Imperial: 66.0 lb x 38.4 lb x 97.2 lb
Metric: 167.64 cm x 97.54 cm x 246.89 cm
Harmonized Code
842121
Harmonized Code Details
842121 - Machinery for filtering or purifying liquids, specifically designed for solvent and chemical handling. This classification covers systems designed for safe flammable liquid management with features like fire-rated enclosures and leak detection.
