Mott Manufacturing SafeGuard Bench Fume Hood, Vertical Sash

Product Information

The Mott Manufacturing SafeGuard Bench Fume Hood is a vertical sash fume hood with a chain and sprocket sash counterbalance system, designed for laboratory safety and efficiency. This brand new unit has never been installed and offers superior visibility of the fume hood interior with its low profile powder coated, type 316 stainless steel hinged airfoil and sash glass. The unit is equipped with UL/CSA approved fluorescent light fixture, duplex receptacles, and a round exhaust collar. It is built for 60-100 ft./min. face velocities, ensuring optimal performance. It is suitable for use in chemical laboratories, pharmaceutical research, and biotechnology applications.

• Vertical rising sash with chain and sprocket sash counterbalance system
• Low profile powder coated, type 316 stainless steel hinged airfoil
• UL/CSA approved fluorescent light fixture and duplex receptacles
• Designed for 60-100 ft./min. face velocities

• Height (Metric) Sash Opening: 45.7 to 74.9 cm
• Width (Metric): 182.8 cm
• Exhaust: At 80 FMP, exhausts 625 CFM at 0.06 static pressure, At 100 FMP, exhausts 781 CFM at 0.10 static pressure, At 60 FMP, exhausts 781 CFM at 0.10 static pressure

Metric: 340.19 kg
Imperial: 750 lb

Metric: 81 cm x 65 cm x 69 cm
Imperial: 31.89 in x 25.59 in x 27.17 in

841989

The harmonized code 841989 is for fume hoods and cabinets with a filtration or purification function, suitable for use in laboratories and similar settings. This code was selected based on the equipment's function and specifications.
