Wastech Stainless Solvent Pump Lift Stations 30-Gallon

Product Information

Welcome to the world of laboratory equipment sophistication with the Wastech Engineering Lab Waist SSPLS-30-007. The stainless solvent pump lift station is designed for safely and efficiently transferring solvents and other flammables when a gravity drain is not possible. Rated for Class 1 Division 1 hazardous environments, this powerhouse can handle the transfer and storage of Group D solvents. Harness the power of corrosion-resistant 316 stainless steel, internal double containment with leak switches, and a fire sprinkler. Safety always comes first in the laboratory! Solvent dispense systems are available in single or dual drum configurations. The interchangeable drums ensure uninterrupted, automatic change-over capabilities while fully contained in a fire-rated enclosure with leak detection and monitoring sensors. Even drum installation and removal have been designed with user safety in mind with features such as stainless steel rollers, and electrical quick disconnects. The standard control panel is remote-mounted and rated for nonhazardous locations. Central or local control panels with PLC controls are also available. Infuse cutting-edge design with safety and efficiency in your laboratory setup.

• Rated for Class 1 Division 1 hazardous environments
• Corrosion resistant 316 stainless steel construction
• Internal double containment with leak switch and fire sprinkler
• Interchangeable drums with automatic change-over capabilities
• Stainless steel rollers for safe and easy drum installation and removal
• Remote-mounted control panel rated for nonhazardous locations

• Tank Volume: 30 gallons
• Pump size: 1/2'' connection
• Configuration: Simplex or duplex
• Material: Fabricated stainless steel tank with 316 stainless steel piping and valves
• Safety: Intrinsically safe multipoint level switch assembly, high-high level switch for high level alarm activation
• Containment: Heavy duty, reinforced 18-gauge all-welded double wall construction, internal double containment with leak switch
• Other Features: Tie downs and adjustable leveling legs, air operated valves for drum dispense control, electrical grounding for cabinet and drums, electrical quick disconnects to remove level switches

Metric: 794.354 kg
Imperial: 1750 lbs

Metric: 142.24 cm x 142.24 cm x 142.24 cm
Imperial: 56 in x 56 in x 56 in

8413815080

This product falls under subheading 8413.81.50 in the Harmonized Tariff Schedule, which covers specifically designed or prepared equipment for the treatment of materials by a process involving a change of temperature, including cremation retorts and incinerators.
