Agilent Technologies 3499A Switch Control High-Speed ATE System
Agilent Technologies
Details
-
CategoryComputer / IT
-
Dimension18.0in x 15.0in x 4.0in
-
Serial40053089
-
Shipping TypeFedEx Ground
-
ManufacturingDoes Not Apply
-
Voltage / Hertz120V/220V / Does Not Apply
Description
The Agilent Technologies 3499A, in good used condition, is a versatile switch control unit designed for high-speed, high-density switching in electronic and optical automated test environments. This unit offers up to five module slots and supports routing up to 200 channels, making it ideal for complex multi-channel applications. The 3499A system can accommodate a variety of electronic and fiber-optic modules, enabling scanning rates of up to 350 channels per second or the ability to open/close 200 channels in under 0.1 seconds. It is compact, fitting into a standard 2U rack height and providing easy wiring options with multi-function modules. The unit supports a wide range of electronic signals from DC to 26.5 GHz and voltages up to 250V with currents up to 8A. Power cord included, computer/software not included.
Key Features
- High-speed switching system
- Supports electronic/optical ATE applications
- Accommodates up to 5 plug-in modules
- Routes up to 200 channels
- Scans up to 350 channels/sec
Specifications
- Model: Agilent 3499A
- Condition: Good, Used
- Voltage: 120V/220V
- Channel Capacity: Up to 200
- Frequency Range: DC to 26.5 GHz
- Current Range: 1 mA to 8A
- Voltage Range: 1 mV to 1000 V
- Rack Size: 2U Height
Weight
Imperial: 12.0 Pounds
Metric: 5.44 Kilograms
Shipping Dimensions
Imperial: 21.6 lb x 18.0 lb x 4.8 lb
Metric: 54.86 cm x 45.72 cm x 12.19 cm
Harmonized Code
9030.39.01
Harmonized Code Details
Harmonized code 9030.39.01 refers to other instruments and apparatus, for measuring or checking voltage, current, resistance or power. This code is suitable as the Agilent 3499A is used in electronic testing environments to manage and direct electronic signals.
