Powervar ABC15.0-20D40Y Power Conditioner Isolation Transformer Surge Diverter
Powervar
Details
-
CategoryMiscellaneous
-
Dimension30.0in x 18.0in x 26.0in
-
Serial7401554-R0940032
-
Shipping TypeFreight
-
ManufacturingDoes Not Apply
-
Voltage / Hertz120V/220V / 50Hz/60Hz
Description
The Powervar ABC15.0-20D40Y Global Power Interface (GPI) Series 2000 Power Conditioner is engineered to ensure superior power conditioning for your equipment. Manufactured in the United States, this unit integrates a low impedance isolation transformer, a surge diverter, and a power line filter to eliminate unwanted noise, spikes, and transients, thereby protecting valuable laboratory equipment. Standard features of this model include safety interlocks, an emergency machine-off (EMO) switch, lockout/tagout breaker, and casters for ease of movement. Its impressive efficiency of over 97% at full load with a unity power factor highlights the model's energy-saving capability. In terms of noise suppression, the output voltage remains below 10 volts in normal mode and under 0.5 volts in common mode, ensuring minimal interference. This used, very good condition unit functions as intended with only minimal cosmetic damage, supporting confident usability in laboratory settings.
Key Features
- Low impedance isolation transformer
- Surge diverter for noise reduction
- Power line filter to eliminate transients
- Safety interlocks and EMO for safety
- Casters for mobility
Specifications
- BTU/Hr. Output: 1536
- Efficiency: > 97% at full load with unity power factor
- Step Load Change: + 0.8% at unity power factor
- Noise Rejection: Less than 10 volts normal mode, less than .5 volts common mode
Weight
Imperial: 390.0 Pounds
Metric: 176.9 Kilograms
Shipping Dimensions
Imperial: 36.0 lb x 21.6 lb x 31.2 lb
Metric: 91.44 cm x 54.86 cm x 79.25 cm
Harmonized Code
8504.50.40
Harmonized Code Details
Harmonized code 8504.50.40 corresponds to 'Static converters' used mainly for power supply applications, such as battery chargers and power conditioners. This code is justified given the Powervar ABC15.0-20D40Y's role as a power conditioner.
