Sorvall SM-24 Rotor Fixed Angle Centrifuge Max Speed 20,500 RPM 24x16mL
Sorvall
Details
-
CategoryCentrifugation
-
Dimension9.0in x 9.0in x 6.0in
-
SerialN/A
-
Shipping TypeFedEx Ground
-
ManufacturingDoes Not Apply
-
Voltage / HertzDoes Not Apply / Does Not Apply
Description
The Sorvall SM-24 Fixed Angle Rotor, manufactured by Sorvall in the United States, is a versatile and reliable rotor designed for centrifugation applications in laboratories. This used rotor, showing slight signs of wear, provides excellent performance with a capacity to hold up to 24-place x 16 ml tubes, reaching a maximum speed of 20,500 RPM. The rotor includes a lid, ensuring secure operation during high-speed spins. With a maximum relative centrifugal force (RCF) of 42,717 x g, it is ideal for labs requiring high-speed separation for processing biological samples. Key specifications include a radius of 110.7 mm, tube dimensions of 18 x 102 mm, and angles of 28 degrees. The rotor's K Factor is 434 for the outer and 591 for the inner tubes, enabling efficient separation dynamics. Although not all testing could be completed, the equipment powers on, and initial assessments suggest it functions correctly.
Key Features
- Capacity for 24 x 16 mL tubes
- Maximum speed of 20,500 RPM
- Relative centrifugal force (RCF) of 42,717 x g
- Radius: 110.7 mm
- Tube dimensions: 18 x 102 mm
- Fixed angle of 28 degrees
- Includes rotor lid
Specifications
- Maximum Speed: 20,500 RPM
- Maximum RCF: 42,717 x g
- Maximum Capacity: 24 x 16 mL
- Radius: 110.7 mm
- Tube Dimensions: 18 x 102 mm
- Angle: 28 degrees
- K Factor: 434 (Outer); 591 (Inner)
Weight
Imperial: 20.4 Pounds
Metric: 9.25 Kilograms
Shipping Dimensions
Imperial: 10.8 lb x 10.8 lb x 7.2 lb
Metric: 27.43 cm x 27.43 cm x 18.29 cm
Harmonized Code
842119
Harmonized Code Details
842119 - Centrifuges, including centrifugal dryers: Other centrifugal machines, nesi; Used for laboratory equipment such as rotors and centrifuges for separating substances.
