Huber HTS 30-H24 Heat Transfer Chiller Heater Adjustable 5...90C Circulation
Huber
Details
-
CategoryChiller / Heater
-
Dimension15.75in x 18.9in x 24.41in
-
SerialS404258
-
Shipping TypeFreight
-
ManufacturingDoes Not Apply
-
Voltage / Hertz415V / 50Hz UK
Description
The Huber HTS 30-H24 Heat Transfer Unit is a reliable and efficient system designed for precise temperature control in a variety of laboratory and industrial applications. Manufactured in Germany, this unit is in very good condition and remains fully functional. It features a robust heat exchanger made from stainless steel and an external plate heat exchanger with copper soldering. Equipped with the advanced Pilot ONE controller, it offers a 5.7-inch touchscreen display, USB and network connections, and multilingual support. This versatile unit supports self-optimizing temperature control modes and programming capabilities, making it ideal for complex heating and cooling processes in sectors such as pharmaceuticals and biotechnology. With a temperature range of 5 to 90 degrees Celsius and a cooling power of up to 30 kW, this unit provides exceptional performance and durability for demanding environments.
Key Features
- Manufactured in Germany
- Heat transfer with stainless steel circulation pump
- Digital level indicator
- Temperature range: 5...90C
- Cooling power: up to 30 kW
- Pilot ONE controller with 5.7-inch touchscreen
- USB and network connectivity
- Supports DIN 12876
Specifications
- Power supply: 3 phase, 400V, 50Hz
- Max current: 5 A, Fuse protection: 3x10 A
- Operating temperature range: 5...90C
- Temperature stability: 0.1 K
- Cooling capacity at 20C: 30 kW
- Circulation pump max delivery: 240 l/min, max pressure: 4.7 bar
- USB and Ethernet interfaces included
- Compatible with multiple programs and ramps
Weight
Imperial: 1891.56 Pounds
Metric: 858.0 Kilograms
Shipping Dimensions
Imperial: 18.9 lb x 22.68 lb x 29.29 lb
Metric: 48.01 cm x 57.61 cm x 74.4 cm
Harmonized Code
84198998
Harmonized Code Details
84198998 corresponds to 'Machinery, Plant or Laboratory Equipment: For Treatment of Materials by a Process Involving a Change of Temperature'. This code is applicable to the Huber HTS 30-H24 as it is a heat transfer unit designed for precise temperature control in laboratory and industrial settings.
