Gilson 306 HPLC Pump Analytical HPLC 10-200 mL/min Flow Rate Multi-Pump
Gilson
Details
-
CategoryHPLC / FPLC / GC / CE
-
Dimension15.0in x 12.0in x 6.0in
-
Serial361G5D019
-
Shipping TypeFedEx Ground
-
ManufacturingDoes Not Apply
-
Voltage / Hertz120V / 60Hz US
Description
The Gilson 306 HPLC Pump delivers a reliable and cost-effective solution for analytical to preparative High Performance Liquid Chromatography (HPLC). Manufactured by Gilson, a reputable name in chromatography, this model offers customizable flow rates from 10 L/min to 200 mL/min, enabling versatility for various liquid viscosities. Designed primarily for multi-pump applications, the 306 serves as a slave pump, controllable via a Gilson master pump or through a compatible software interface. Enhancements like manometric modules and dynamic mixers are available to improve pressure stability and mixing efficiency. Despite being used, the pump powers on successfully and passes basic tests, indicating functional integrity. Originating from the United States, it operates on a 120V, 60 Hz power supply.
Key Features
- Flexible flow rates from 10 L/min to 200 mL/min
- Compatible with various liquid viscosities
- Slave pump for multi-unit configurations
- Controlled via computer software or Gilson 305
- Supports HPLC in isocratic and gradient forms
- Manometric modules and dynamic mixers for stable pressure
Specifications
- Flow Rate Range: 10 L/min to 200 mL/min
- Power Requirements: 120V, 60 Hz
- Purification Technique: HPLC
- Hydraulic System: Reciprocating pump with single-piston interchangeable head
- Operating Pressure: 0.160 MPa (1-600 bar, 14.5-8700 psi)
- Pump Configurations: Isocratic, binary, and tertiary
Weight
Imperial: 12.0 Pounds
Metric: 5.44 Kilograms
Shipping Dimensions
Imperial: 18.0 lb x 14.4 lb x 7.2 lb
Metric: 45.72 cm x 36.58 cm x 18.29 cm
Harmonized Code
84133090
Harmonized Code Details
Harmonized code 84133090 covers pumps for liquids, part of machinery used for laboratory settings. This classification suits the Gilson 306 HPLC Pump given its function and application in chromatography.
